– 122 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
R8382 1-216-033-00 RES-CHIP 220 5% 1/10W
R8383 1-216-033-00 RES-CHIP 220 5% 1/10W
R8384 1-216-025-11 RES-CHIP 100 5% 1/10W
R8388 1-216-033-00 RES-CHIP 220 5% 1/10W
R8390 1-216-037-00 RES-CHIP 330 5% 1/10W
R8391 1-216-041-00 RES-CHIP 470 5% 1/10W
R8395 1-216-033-00 RES-CHIP 220 5% 1/10W
R8396 1-216-033-00 RES-CHIP 220 5% 1/10W
R8399 1-216-025-11 RES-CHIP 100 5% 1/10W
R8400 1-216-025-11 RES-CHIP 100 5% 1/10W
R8411 1-216-083-00 RES-CHIP 27K 5% 1/10W
R8414 1-208-796-11 METAL CHIP 3.9K 0.5% 1/10W
R8415 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8417 1-216-025-11 RES-CHIP 100 5% 1/10W
R8418 1-216-025-11 RES-CHIP 100 5% 1/10W
R8419 1-216-017-91 RES-CHIP 47 5% 1/10W
R8420 1-216-017-91 RES-CHIP 47 5% 1/10W
R8435 1-216-295-91 SHORT CHIP 0
R8441 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8442 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8446 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8447 1-216-025-11 RES-CHIP 100 5% 1/10W
R8448 1-216-025-11 RES-CHIP 100 5% 1/10W
R8449 1-216-025-11 RES-CHIP 100 5% 1/10W
R8450 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8451 1-216-097-11 RES-CHIP 100K 5% 1/10W
R8452 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8453 1-216-097-11 RES-CHIP 100K 5% 1/10W
R8454 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8455 1-216-097-11 RES-CHIP 100K 5% 1/10W
R8464 1-216-025-11 RES-CHIP 100 5% 1/10W
R8465 1-216-025-11 RES-CHIP 100 5% 1/10W
R8466 1-216-025-11 RES-CHIP 100 5% 1/10W
R8467 1-216-041-00 RES-CHIP 470 5% 1/10W
R8468 1-216-041-00 RES-CHIP 470 5% 1/10W
R8469 1-216-041-00 RES-CHIP 470 5% 1/10W
R8470 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R8471 1-216-025-11 RES-CHIP 100 5% 1/10W
R8478 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8479 1-216-097-11 RES-CHIP 100K 5% 1/10W
R8480 1-216-073-91 RES-CHIP 10K 5% 1/10W
R8481 1-216-095-00 RES-CHIP 82K 5% 1/10W
R8482 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8484 1-216-045-00 RES-CHIP 680 5% 1/10W
R8485 1-216-037-00 RES-CHIP 330 5% 1/10W
R8486 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8487 1-216-045-00 RES-CHIP 680 5% 1/10W
R8488 1-216-041-00 RES-CHIP 470 5% 1/10W
R8489 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8490 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8491 1-216-025-11 RES-CHIP 100 5% 1/10W
R8492 1-216-041-00 RES-CHIP 470 5% 1/10W
R8493 1-216-081-00 RES-CHIP 22K 5% 1/10W
R8494 1-216-041-00 RES-CHIP 470 5% 1/10W
R8495 1-216-081-00 RES-CHIP 22K 5% 1/10W
R8496 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8497 1-216-025-11 RES-CHIP 100 5% 1/10W
R8498 1-216-043-91 RES-CHIP 560 5% 1/10W
R8499 1-216-081-00 RES-CHIP 22K 5% 1/10W
R8500 1-216-033-00 RES-CHIP 220 5% 1/10W
R8501 1-216-081-00 RES-CHIP 22K 5% 1/10W
R8502 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8507 1-216-025-11 RES-CHIP 100 5% 1/10W
R8508 1-216-025-11 RES-CHIP 100 5% 1/10W
R8512 1-216-017-91 RES-CHIP 47 5% 1/10W
R8536 1-216-025-11 RES-CHIP 100 5% 1/10W
R8538 1-216-041-00 RES-CHIP 470 5% 1/10W
R8540 1-216-041-00 RES-CHIP 470 5% 1/10W
R8541 1-216-039-00 RES-CHIP 390 5% 1/10W
R8576 1-216-013-00 RES-CHIP 33 5% 1/10W
R8577 1-216-295-91 SHORT CHIP 0
R8578 1-216-033-00 RES-CHIP 220 5% 1/10W
R8579 1-216-295-91 SHORT CHIP 0
R8582 1-208-291-11 RES-CHIP 4.7M 5% 1/10W
R8583 1-208-291-11 RES-CHIP 4.7M 5% 1/10W
R8584 1-208-291-11 RES-CHIP 4.7M 5% 1/10W
R8587 1-216-295-91 SHORT CHIP 0
R8588 1-216-041-00 RES-CHIP 470 5% 1/10W
R8589 1-216-041-00 RES-CHIP 470 5% 1/10W
R8590 1-216-041-00 RES-CHIP 470 5% 1/10W
<TUNER>
TU101 8-598-452-20 TUNER, FSS BTF-WG442 (KV-DR29M39/M69)
TU101 8-598-451-00 TUNER, FSS BTF-WG441 (KV-DR29M63)
TU101 8-598-450-10 TUNER, FSS BTF-LG434 (KV-DR29M89)
TU3301 8-598-450-10 TUNER, FSS BTF-LG434
(KV-DR29M39/M69/M89)
<CRYSTAL>
X001 1-567-928-11 VIBLATOR, CERAMIC
X3001 1-781-922-21 VIBRATOR, CERAMIC
X4301 1-760-895-21 VIBRATOR, CERAMIC
X8301 1-781-612-11 VIBRATOR, CRYSTAL
************************************************************** *
* A-1300-290-A B3 BOARD COMPLETE
(KV-DR29M39/DR29M69/DR29M89)
* A-1300-385-A B3 BOARD COMPLETE (KV-DR29M63)
***********************************
<CAPACITOR>
C501 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C502 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C503 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C505 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C507 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C512 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C539 1-126-204-11 ELECT CHIP 47UF 20.00% 16V
C540 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C543 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C545 1-126-396-11 ELECT CHIP 47UF 20.00% 16V
C546 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C548 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C549 1-126-204-11 ELECT CHIP 47UF 20.00% 16V
C550 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C551 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
B3
A
To Next Page
