Sony TRINITRON KV-DR29M39 - Page 105

– 123 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
C554 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C555 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C556 1-126-396-11 ELECT CHIP 47UF 20.00% 16V
C557 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C559 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C560 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C601 1-126-394-11 ELECT CHIP 10UF 20.00% 16V
C602 1-126-394-11 ELECT CHIP 10UF 20.00% 16V
C603 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C604 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C605 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C606 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C607 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C608 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C609 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C610 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C611 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C612 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C613 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C614 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C615 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C616 1-126-396-11 ELECT CHIP 47UF 20.00% 16V
C617 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C618 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C619 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C620 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C621 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C622 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C623 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C624 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C625 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C626 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C627 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C628 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C629 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C630 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C631 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C632 1-126-206-11 ELECT CHIP 100UF 20.00% 6.3V
C633 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C634 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C635 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C636 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C637 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C638 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C639 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C640 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C642 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C643 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C644 1-126-398-11 ELECT CHIP 4.7UF 20.00% 35V
C645 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C652 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C653 1-126-206-11 ELECT CHIP 100UF 20.00% 6.3V
C801 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C802 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C803 1-126-206-11 ELECT CHIP 100UF 20.00% 6.3V
C804 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C805 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C806 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C807 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C808 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C809 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C810 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C811 1-163-023-00 CERAMIC CHIP 0.015UF 10.00% 50V
C812 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C813 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C814 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C815 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C816 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C817 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C818 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C819 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C820 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C821 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C822 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C823 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C824 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C825 1-126-204-11 ELECT CHIP 47UF 20.00% 16V
C826 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C831 1-126-204-11 ELECT CHIP 47UF 20.00% 16V
C833 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C834 1-126-204-11 ELECT CHIP 47UF 20.00% 16V
<CONNECTOR>
CN502 1-793-497-11 CONNECTOR, BOARD TO BOARD 40P
<DIODE>
D501 8-719-082-02 DIODE MM3Z3V9T1
D601 8-719-081-97 MMDL914T1
D800 8-719-081-97 MMDL914T1
<FERRITE BEAD>
FB501 1-414-813-11 FERRITE 0UH
FB502 1-414-813-11 FERRITE 0UH
FB503 1-414-813-11 FERRITE 0UH
FB504 1-414-813-11 FERRITE 0UH
FB601 1-414-553-11 FERRITE 0UH
<FILTER>
FL501 1-233-877-11 FILTER, LOW PASS
FL502 1-233-504-21 FILTER, LOW PASS
FL503 1-233-504-21 FILTER, LOW PASS
FL504 1-234-177-21 FERRITE 0UH
FL505 1-234-177-21 FERRITE 0UH
FL506 1-234-177-21 FERRITE 0UH
FL601 1-234-177-21 FERRITE 0UH
FL602 1-234-177-21 FERRITE 0UH
FL603 1-234-177-21 FERRITE 0UH
FL801 1-234-177-21 FERRITE 0UH
FL901 1-234-113-21 FILTER, LOW PASS
FL902 1-234-112-21 FILTER, LOW PASS
FL903 1-234-112-21 FILTER, LOW PASS
<IC>
IC504 8-759-669-78 TLC2933IPWR-12
IC505 8-759-547-54 TC7SET00FU(TE85
IC506 8-759-547-54 TC7SET00FU(TE85
