– 124 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
IC601 8-752-409-78 IC CXD2095AQ
IC602 8-759-836-37 IC MT48LC1M16A1TG-6S
IC603 8-759-669-75 TLC2932IPWR
IC604 8-752-072-94 CXA1875AM-T4
IC605 8-749-015-18 PQ07VZ012ZP
IC801 6-700-188-01 IC IS41C16256-35K
IC802 6-701-892-01 IC TC90A90F(BH,DRY)
IC803 8-749-015-18 PQ07VZ012ZP
<CHIP CONDUCTOR>
JR601 1-216-295-91 SHORT CHIP 0
JR801 1-216-295-91 SHORT CHIP 0
<COIL>
L503 1-412-026-11 INDUCTOR 1UH
L505 1-412-029-11 INDUCTOR 10UH
L506 1-412-026-11 INDUCTOR 1UH
L508 1-412-029-11 INDUCTOR 10UH
L509 1-412-029-11 INDUCTOR 10UH
L512 1-412-026-11 INDUCTOR 1UH
L604 1-412-029-11 INDUCTOR 10UH
L605 1-412-029-11 INDUCTOR 10UH
L801 1-412-026-11 INDUCTOR 1UH
L802 1-412-026-11 INDUCTOR 1UH
L804 1-412-026-11 INDUCTOR 1UH
L805 1-412-026-11 INDUCTOR 1UH
L806 1-412-026-11 INDUCTOR 1UH
L807 1-412-026-11 INDUCTOR 1UH
<TRANSISTOR>
Q501 8-729-010-05 MSB709-RT1
Q502 8-729-120-28 2SC1623-L5L6
Q503 8-729-120-28 2SC1623-L5L6
Q504 8-729-421-19 UN2213
Q516 8-729-010-25 MSD601-RT1
Q517 8-729-010-25 MSD601-RT1
Q518 8-729-010-05 MSB709-RT1
Q521 8-729-010-25 MSD601-RT1
Q522 8-729-010-25 MSD601-RT1
Q523 8-729-010-25 MSD601-RT1
Q602 8-729-010-25 MSD601-RT1
Q605 8-729-010-25 MSD601-RT1
Q606 8-729-010-25 MSD601-RT1
Q607 8-729-900-53 DTC114EK
Q901 8-729-010-05 MSB709-RT1
Q902 8-729-010-05 MSB709-RT1
Q903 8-729-010-05 MSB709-RT1
Q907 8-729-010-05 MSB709-RT1
Q908 8-729-010-05 MSB709-RT1
Q909 8-729-010-05 MSB709-RT1
<RESISTOR>
R501 1-216-025-11 RES-CHIP 100 5% 1/10W
R502 1-216-025-11 RES-CHIP 100 5% 1/10W
R503 1-216-295-91 SHORT CHIP 0
R504 1-216-295-91 SHORT CHIP 0
R505 1-216-295-91 SHORT CHIP 0
R506 1-216-025-11 RES-CHIP 100 5% 1/10W
R507 1-216-025-11 RES-CHIP 100 5% 1/10W
R513 1-216-639-11 METAL CHIP 330 0.5% 1/10W
R514 1-216-639-11 METAL CHIP 330 0.5% 1/10W
R515 1-216-639-11 METAL CHIP 330 0.5% 1/10W
R517 1-216-049-11 RES-CHIP 1K 5% 1/10W
R518 1-216-295-91 SHORT CHIP 0
R520 1-208-776-11 METAL CHIP 560 0.5% 1/10W
R521 1-216-295-91 SHORT CHIP 0
R523 1-208-776-11 METAL CHIP 560 0.5% 1/10W
R524 1-216-295-91 SHORT CHIP 0
R526 1-208-776-11 METAL CHIP 560 0.5% 1/10W
R528 1-216-037-00 RES-CHIP 330 5% 1/10W
R529 1-208-800-11 METAL CHIP 5.6K 0.5% 1/10W
R530 1-208-800-11 METAL CHIP 5.6K 0.5% 1/10W
R531 1-216-031-00 RES-CHIP 180 5% 1/10W
R532 1-208-800-11 METAL CHIP 5.6K 0.5% 1/10W
R533 1-216-031-00 RES-CHIP 180 5% 1/10W
R537 1-216-643-11 METAL CHIP 470 0.5% 1/10W
R538 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R539 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R561 1-216-043-91 RES-CHIP 560 5% 1/10W
R562 1-216-043-91 RES-CHIP 560 5% 1/10W
R563 1-216-043-91 RES-CHIP 560 5% 1/10W
R564 1-216-049-11 RES-CHIP 1K 5% 1/10W
R598 1-216-025-11 RES-CHIP 100 5% 1/10W
R600 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R604 1-216-033-00 RES-CHIP 220 5% 1/10W
R605 1-216-295-91 SHORT CHIP 0
R608 1-216-295-91 SHORT CHIP 0
R609 1-216-073-91 RES-CHIP 10K 5% 1/10W
R610 1-216-033-00 RES-CHIP 220 5% 1/10W
R611 1-216-073-91 RES-CHIP 10K 5% 1/10W
R612 1-216-073-91 RES-CHIP 10K 5% 1/10W
R613 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R614 1-216-295-91 SHORT CHIP 0
R615 1-216-089-91 RES-CHIP 47K 5% 1/10W
R616 1-216-073-91 RES-CHIP 10K 5% 1/10W
R617 1-216-295-91 SHORT CHIP 0
R619 1-216-073-91 RES-CHIP 10K 5% 1/10W
R622 1-216-295-91 SHORT CHIP 0
R623 1-216-295-91 SHORT CHIP 0
R624 1-216-295-91 SHORT CHIP 0
R626 1-216-073-91 RES-CHIP 10K 5% 1/10W
R628 1-216-295-91 SHORT CHIP 0
R629 1-216-073-91 RES-CHIP 10K 5% 1/10W
R631 1-216-295-91 SHORT CHIP 0
R634 1-216-295-91 SHORT CHIP 0
R635 1-216-295-91 SHORT CHIP 0
R638 1-216-295-91 SHORT CHIP 0
R639 1-216-017-91 RES-CHIP 47 5% 1/10W
R640 1-216-009-91 RES-CHIP 22 5% 1/10W
R642 1-216-295-91 SHORT CHIP 0
R643 1-216-295-91 SHORT CHIP 0
R645 1-216-295-91 SHORT CHIP 0
R647 1-216-295-91 SHORT CHIP 0
R648 1-208-782-11 METAL CHIP 1K 0.5% 1/10W
R650 1-211-960-11 METAL CHIP 22 0.5% 1/10W
R651 1-216-295-91 SHORT CHIP 0
R653 1-216-025-11 RES-CHIP 100 5% 1/10W
B3
