– 126 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
* A-1300-298-A BC1 BOARD COMPLETE
(KV-DR29M39/DR29M69/DR29M89)
* A-1300-388-A BC1 BOARD COMPLETE (KV-DR29M63)
************************************
<CAPACITOR>
C2001 1-126-947-11 ELECT 47UF 20.00% 16V
C2002 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C2003 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C2004 1-107-698-11 ELECT 10UF 20.00% 25V
C2005 1-163-131-00 CERAMIC CHIP 390PF 5.00% 50V
C2006 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2007 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2008 1-104-665-11 ELECT 100UF 20.00% 10V
C2009 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2010 1-163-102-00 CERAMIC CHIP 24PF 5.00% 50V
C2011 1-163-102-00 CERAMIC CHIP 24PF 5.00% 50V
C2012 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2013 1-126-947-11 ELECT 47UF 20.00% 16V
C2014 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2016 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2018 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2019 1-126-947-11 ELECT 47UF 20.00% 16V
C2021 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2022 1-126-947-11 ELECT 47UF 20.00% 16V
C2023 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2024 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2025 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2026 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2027 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2028 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2029 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2030 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2032 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2033 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2034 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2035 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2036 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2037 1-126-947-11 ELECT 47UF 20.00% 16V
C2038 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2039 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2040 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2041 1-126-947-11 ELECT 47UF 20.00% 16V
C2044 1-104-665-11 ELECT 100UF 20.00% 10V
C2045 1-163-106-00 CERAMIC CHIP 36PF 5.00% 50V
C2046 1-126-964-11 ELECT 10UF 20.00% 50V
C2047 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C2048 1-126-964-11 ELECT 10UF 20.00% 50V
C2049 1-126-960-11 ELECT 1UF 20.00% 50V
C2050 1-163-231-11 CERAMIC CHIP 15PF 5.00% 50V
C2051 1-126-964-11 ELECT 10UF 20.00% 50V
C2052 1-163-133-00 CERAMIC CHIP 470PF 5.00% 50V
C2053 1-109-889-11 ELECT 1UF 20.00% 50V
C2054 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2055 1-126-947-11 ELECT 47UF 20.00% 16V
C2056 1-163-231-11 CERAMIC CHIP 15PF 5.00% 50V
C2058 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2063 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2064 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2066 1-126-947-11 ELECT 47UF 20.00% 16V
C2072 1-163-237-11 CERAMIC CHIP 27PF 5.00% 50V
C2074 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2075 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2078 1-126-947-11 ELECT 47UF 20.00% 16V
C2079 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2081 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C2096 1-163-231-11 CERAMIC CHIP 15PF 5.00% 50V
C2097 1-163-231-11 CERAMIC CHIP 15PF 5.00% 50V
C2100 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C2101 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2103 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2104 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2105 1-163-031-91 CERAMIC CHIP 0.01UF 50V
C2300 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C2301 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C2302 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C2303 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C2304 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C2305 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C2306 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C2307 1-126-933-11 ELECT 100UF 20.00% 16V
C2308 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C2309 1-126-947-11 ELECT 47UF 20.00% 16V
C2310 1-126-947-11 ELECT 47UF 20.00% 16V
C2312 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C2313 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C2314 1-163-007-11 CERAMIC CHIP 680PF 10.00% 50V
C2315 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C2316 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C2317 1-126-933-11 ELECT 100UF 20.00% 16V
C2318 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C2319 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C2320 1-163-229-11 CERAMIC CHIP 12PF 5.00% 50V
C2321 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C2322 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C2323 1-163-229-11 CERAMIC CHIP 12PF 5.00% 50V
C2324 1-126-947-11 ELECT 47UF 20.00% 16V
C2326 1-126-947-11 ELECT 47UF 20.00% 16V
C2327 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C2330 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C2331 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
<CONNECTOR>
CN2001 1-793-496-11 CONNECTOR, BOARD TO BOARD 20P
<FERRITE BEAD>
FB2001 1-414-234-22 FERRITE 0UH
FB2002 1-414-234-22 FERRITE 0UH
FB2008 1-414-234-22 FERRITE 0UH
FB2010 1-414-234-22 FERRITE 0UH
FB2011 1-414-234-22 FERRITE 0UH
FB2012 1-414-234-22 FERRITE 0UH
FB2014 1-414-234-22 FERRITE 0UH
FB2015 1-414-234-22 FERRITE 0UH
FB2016 1-216-295-91 SHORT CHIP 0
FB2017 1-216-295-91 SHORT CHIP 0
<FILTER>
FL2000 1-236-071-11 ENCAPSULATED COMPONENT
FL2001 1-239-848-11 FILTER, LOW PASS
BC1
To Next Page
