Sony TRINITRON KV-DR29M39 - Page 109

– 127 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
FL2002 1-239-848-11 FILTER, LOW PASS
FL2003 1-239-848-11 FILTER, LOW PASS
FL2004 1-239-848-11 FILTER, LOW PASS
<IC>
IC2001 6-700-394-01 IC BA25BC0FP-E2
IC2004 6-700-960-01 IC UPD64083GF-3BA
IC2005 8-759-460-72 BA033FP-E2
IC2300 6-701-972-01 IC TC90A69F
<COIL>
L2001 1-410-200-31 INDUCTOR 4.7UH
L2002 1-412-058-11 INDUCTOR 10UH
L2003 1-412-058-11 INDUCTOR 10UH
L2005 1-412-058-11 INDUCTOR 10UH
L2006 1-412-058-11 INDUCTOR 10UH
L2007 1-412-058-11 INDUCTOR 10UH
L2008 1-412-058-11 INDUCTOR 10UH
L2300 1-412-058-11 INDUCTOR 10UH
L2301 1-412-031-11 INDUCTOR 47UH
L2302 1-412-031-11 INDUCTOR 47UH
L2303 1-412-031-11 INDUCTOR 47UH
L2304 1-410-514-11 INDUCTOR 27UH
L2305 1-410-514-11 INDUCTOR 27UH
L2306 1-412-058-11 INDUCTOR 10UH
L2307 1-412-026-11 INDUCTOR 1UH
<TRANSISTOR>
Q2002 8-729-026-49 2SA1037AK-T146-R
Q2003 8-729-026-49 2SA1037AK-T146-R
Q2004 8-729-026-49 2SA1037AK-T146-R
Q2005 8-729-010-25 MSD601-RT1
Q2006 8-729-010-25 MSD601-RT1
Q2007 8-729-010-25 MSD601-RT1
Q2008 8-729-010-25 MSD601-RT1
Q2009 8-729-010-25 MSD601-RT1
Q2010 8-729-010-25 MSD601-RT1
Q2011 8-729-010-25 MSD601-RT1
Q2012 8-729-026-49 2SA1037AK-T146-R
Q2013 8-729-026-49 2SA1037AK-T146-R
Q2014 8-729-010-25 MSD601-RT1
Q2015 8-729-010-25 MSD601-RT1
Q2016 8-729-010-25 MSD601-RT1
Q2018 8-729-026-49 2SA1037AK-T146-R
Q2019 8-729-010-25 MSD601-RT1
Q2301 8-729-026-49 2SA1037AK-T146-R
Q2302 8-729-010-25 MSD601-RT1
Q2303 8-729-010-25 MSD601-RT1
Q2304 8-729-026-49 2SA1037AK-T146-R
Q2305 8-729-010-25 MSD601-RT1
Q2306 8-729-010-25 MSD601-RT1
Q2307 8-729-010-25 MSD601-RT1
Q2308 8-729-026-49 2SA1037AK-T146-R
Q2309 8-729-010-25 MSD601-RT1
<RESISTOR>
R2001 1-216-073-91 RES-CHIP 10K 5% 1/10W
R2002 1-216-295-91 SHORT CHIP 0
R2004 1-216-295-91 SHORT CHIP 0
R2005 1-216-295-91 SHORT CHIP 0
R2011 1-216-041-00 RES-CHIP 470 5% 1/10W
R2012 1-216-073-91 RES-CHIP 10K 5% 1/10W
R2015 1-216-041-00 RES-CHIP 470 5% 1/10W
R2021 1-216-025-11 RES-CHIP 100 5% 1/10W
R2027 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2028 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2029 1-216-043-91 RES-CHIP 560 5% 1/10W
R2030 1-216-043-91 RES-CHIP 560 5% 1/10W
R2031 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R2032 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R2033 1-216-037-00 RES-CHIP 330 5% 1/10W
R2034 1-216-037-00 RES-CHIP 330 5% 1/10W
R2035 1-216-043-91 RES-CHIP 560 5% 1/10W
R2036 1-216-644-11 METAL CHIP 510 0.5% 1/10W
R2037 1-216-045-00 RES-CHIP 680 5% 1/10W
R2039 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R2040 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R2041 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R2042 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R2043 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R2044 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R2046 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R2047 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R2048 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2049 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R2050 1-216-017-91 RES-CHIP 47 5% 1/10W
R2051 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2052 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2053 1-216-041-00 RES-CHIP 470 5% 1/10W
R2054 1-216-041-00 RES-CHIP 470 5% 1/10W
R2055 1-216-017-91 RES-CHIP 47 5% 1/10W
R2056 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R2057 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2058 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R2059 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2060 1-216-025-11 RES-CHIP 100 5% 1/10W
R2061 1-216-043-91 RES-CHIP 560 5% 1/10W
R2062 1-216-105-91 RES-CHIP 220K 5% 1/10W
R2063 1-216-089-91 RES-CHIP 47K 5% 1/10W
R2064 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2066 1-216-033-00 RES-CHIP 220 5% 1/10W
R2067 1-216-043-91 RES-CHIP 560 5% 1/10W
R2069 1-216-639-11 METAL CHIP 330 0.5% 1/10W
R2070 1-216-641-11 METAL CHIP 390 0.5% 1/10W
R2071 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R2072 1-216-043-91 RES-CHIP 560 5% 1/10W
R2073 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2074 1-216-025-11 RES-CHIP 100 5% 1/10W
R2076 1-216-025-11 RES-CHIP 100 5% 1/10W
R2077 1-216-025-11 RES-CHIP 100 5% 1/10W
R2108 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2115 1-216-041-00 RES-CHIP 470 5% 1/10W
R2301 1-216-041-00 RES-CHIP 470 5% 1/10W
R2306 1-216-039-00 RES-CHIP 390 5% 1/10W
R2307 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2308 1-216-047-91 RES-CHIP 820 5% 1/10W
R2309 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R2310 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R2311 1-216-075-00 RES-CHIP 12K 5% 1/10W
