Sony TRINITRON KV-DR29M39 - Page 110

– 128 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
R2312 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2313 1-216-295-91 SHORT CHIP 0
R2314 1-216-039-00 RES-CHIP 390 5% 1/10W
R2315 1-216-041-00 RES-CHIP 470 5% 1/10W
R2317 1-216-025-11 RES-CHIP 100 5% 1/10W
R2318 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2319 1-216-047-91 RES-CHIP 820 5% 1/10W
R2320 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R2321 1-216-075-00 RES-CHIP 12K 5% 1/10W
R2322 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R2323 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2324 1-216-041-00 RES-CHIP 470 5% 1/10W
R2325 1-216-041-00 RES-CHIP 470 5% 1/10W
R2326 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2327 1-216-017-91 RES-CHIP 47 5% 1/10W
R2328 1-216-017-91 RES-CHIP 47 5% 1/10W
R2330 1-216-037-00 RES-CHIP 330 5% 1/10W
R2331 1-216-295-91 SHORT CHIP 0
R2333 1-216-025-11 RES-CHIP 100 5% 1/10W
R2334 1-216-049-11 RES-CHIP 1K 5% 1/10W
R2335 1-414-234-22 FERRITE 0UH
<VARIABLE RESISTOR>
RV2001 1-223-271-21 RES, ADJ, CERMET 220
<CRYSTAL>
X2001 1-767-606-11 VIBRATOR, CRYSTAL
****************************************************************
* A-1400-488-A C BOARD MOUNTED
(KV-DR29M39/DR29M69/DR29M89)
* A-1400-690-A C BOARD MOUNTED (KV-DR29M63)
*********************************
4-382-854-01 SCREW (M3X8), P, SW (+)
<CAPACITOR>
C9002 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C9003 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C9004 1-104-574-11 CERAMIC 0.0047UF 10.00% 2KV
C9005 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C9006 1-163-091-00 CERAMIC CHIP 8PF 0.25PF 50V
C9007 1-163-091-00 CERAMIC CHIP 8PF 0.25PF 50V
C9008 1-163-091-00 CERAMIC CHIP 8PF 0.25PF 50V
C9009 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C9010 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C9011 1-136-207-11 MYLAR 0.047UF 10.00% 250V
C9012 1-136-207-11 MYLAR 0.047UF 10.00% 250V
C9014 1-136-207-11 MYLAR 0.047UF 10.00% 250V
C9015 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C9016 1-102-106-00 CERAMIC 100PF 10.00% 50V
C9018 1-107-961-91 ELECT 10UF 20.00% 250V
C9019 1-163-035-00 CERAMIC CHIP 0.047UF 50V
C9020 1-107-961-91 ELECT 10UF 20.00% 250V
C9021 1-107-961-91 ELECT 10UF 20.00% 250V
C9022 1-101-004-00 CERAMIC 0.01UF 50V
C9023 1-101-004-00 CERAMIC 0.01UF 50V
C9024 1-163-035-00 CERAMIC CHIP 0.047UF 50V
C9025 1-126-934-11 ELECT 220UF 20.00% 16V
C9026 1-163-035-00 CERAMIC CHIP 0.047UF 50V
C9027 1-101-004-00 CERAMIC 0.01UF 50V
C9028 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C9029 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C9030 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C9031 1-104-574-11 CERAMIC 0.0047UF 10.00% 2KV
C9032 1-162-116-00 CERAMIC 680PF 10.00% 2KV
C9033 1-107-662-11 ELECT 22UF 20.00% 250V
C9035 1-104-574-11 CERAMIC 0.0047UF 10.00% 2KV
C9042 1-126-940-11 ELECT 330UF 20.00% 25V
C9047 1-107-651-11 ELECT 4.7UF 20.00% 250V
<CONNECTOR>
CN9001 * 1-564-512-11 PLUG, CONNECTOR 9P
CN9002 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
(KV-DR29M39/M69/M89)
CN9002 * 1-564-507-11 PLUG, CONNECTOR 4P (KV-DR29M63)
CN9003 1-695-915-11 TAB (CONTACT)
CN9004 1-695-915-11 TAB (CONTACT)
CN9007 1-785-879-11 CONNECTOR, ONE TOUCH
<DIODE>
D9002 8-719-400-75 MA3091
D9005 8-719-404-50 MA111-TX (KV-DR29M39/M69/M89)
D9005 8-719-081-97 MMDL914T1 (KV-DR29M63)
D9006 8-719-051-85 HSS83TD
D9007 8-719-051-85 HSS83TD
D9008 8-719-051-85 HSS83TD
D9009 8-719-908-03 GP08D
D9010 8-719-110-17 RD10ESB2
D9011 1-216-295-91 SHORT CHIP 0
D9012 1-216-295-91 SHORT CHIP 0
D9013 1-216-295-91 SHORT CHIP 0
<IC>
IC9001 8-759-360-83 TDA6111Q/N4
IC9002 8-759-360-83 TDA6111Q/N4
IC9003 8-759-360-83 TDA6111Q/N4
<JACK>
J9001 ! 1-540-071-22 SOCKET, CRT
<COIL>
L9001 1-414-158-11 INDUCTOR 2.2UH
L9002 1-408-591-11 INDUCTOR 1UH
L9003 1-408-591-11 INDUCTOR 1UH
L9004 1-408-591-11 INDUCTOR 1UH
L9005 1-406-666-21 INDUCTOR 150UH
L9006 1-412-526-11 INDUCTOR 12UH
<FILTER>
LP9001 * 4-042-408-01 PIN, COATING LEAD
LP9002 * 4-042-408-01 PIN, COATING LEAD
C
BC1
