– 129 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
LP9003 * 4-042-408-01 PIN, COATING LEAD
LP9004 * 4-042-408-01 PIN, COATING LEAD
<NEON LAMP>
NL9001 1-519-526-11 LAMP, NEON
NL9003 1-519-526-11 LAMP, NEON
<TRANSISTOR>
Q9001 8-729-026-49 2SA1037AK-T146-R (KV-DR29M39/M69/M89)
Q9001 8-729-010-05 MSB709-RT1 (KV-DR29M63)
Q9009 8-729-026-49 2SA1037AK-T146-R (KV-DR29M39/M69/M89)
Q9009 8-729-010-05 MSB709-RT1 (KV-DR29M63)
Q9010 8-729-026-49 2SA1037AK-T146-R (KV-DR29M39/M69/M89)
Q9010 8-729-010-05 MSB709-RT1 (KV-DR29M63)
Q9011 8-729-026-49 2SA1037AK-T146-R (KV-DR29M39/M69/M89)
Q9011 8-729-010-05 MSB709-RT1 (KV-DR29M63)
<RESISTOR>
R9001 1-216-059-00 RES-CHIP 2.7K 5% 1/10W
R9006 1-216-073-91 RES-CHIP 10K 5% 1/10W
R9007 1-208-789-11 METAL CHIP 2K 0.5% 1/10W
R9008 1-216-085-91 RES-CHIP 33K 5% 1/10W
R9012 1-216-049-11 RES-CHIP 1K 5% 1/10W
R9013 1-216-049-11 RES-CHIP 1K 5% 1/10W
R9018 1-216-059-00 RES-CHIP 2.7K 5% 1/10W
R9019 1-216-059-00 RES-CHIP 2.7K 5% 1/10W
R9021 1-216-295-91 SHORT CHIP 0
R9023 1-216-295-91 SHORT CHIP 0
R9026 1-208-789-11 METAL CHIP 2K 0.5% 1/10W
R9031 1-208-789-11 METAL CHIP 2K 0.5% 1/10W
R9033 1-208-808-11 METAL CHIP 12K 0.5% 1/10W
R9034 1-208-800-11 METAL CHIP 5.6K 0.5% 1/10W
R9035 1-208-790-11 METAL CHIP 2.2K 0.5% 1/10W
R9036 1-216-049-11 RES-CHIP 1K 5% 1/10W
R9037 1-240-233-71 METAL OXIDE 100 5% 3W
R9038 1-208-790-11 METAL CHIP 2.2K 0.5% 1/10W
R9039 1-208-790-11 METAL CHIP 2.2K 0.5% 1/10W
R9041 1-216-049-11 RES-CHIP 1K 5% 1/10W
R9042 1-216-049-11 RES-CHIP 1K 5% 1/10W
R9043 1-240-233-71 METAL OXIDE 100 5% 3W
R9044 1-240-233-71 METAL OXIDE 100 5% 3W
R9047 1-219-744-11 CARBON 220 5% 1/2W
R9048 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R9049 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R9050 1-249-424-11 CARBON 3.9K 5% 1/4W
R9051 1-219-744-11 CARBON 220 5% 1/2W
R9052 1-219-744-11 CARBON 220 5% 1/2W
R9053 1-249-424-11 CARBON 3.9K 5% 1/4W
R9054 1-249-424-11 CARBON 3.9K 5% 1/4W
R9055 1-243-994-91 CEMENTED 820K 5% 0.5W
R9056 1-219-750-91 CARBON 22K 5% 1/2W
R9057 1-220-827-91 RESISTOR 560K 5% 1/2W
R9058 1-243-994-91 CEMENTED 820K 5% 0.5W
R9059 1-219-746-11 CARBON 1K 5% 1/2W
R9061 1-219-743-11 CARBON 100 5% 1/2W
R9065 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R9068 1-216-101-00 RES-CHIP 150K 5% 1/10W
R9069 1-219-743-11 CARBON 100 5% 1/2W
R9070 1-216-037-00 RES-CHIP 330 5% 1/10W
R9071 1-216-037-00 RES-CHIP 330 5% 1/10W
R9072 1-216-037-00 RES-CHIP 330 5% 1/10W
R9073 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
<VARIABLE RESISTOR>
RV9001 1-241-656-11 RES, ADJ, METAL FILM 110M
RV9002 1-230-641-11 RES, ADJ, METAL GLAZE 2.2M
***************************************************************
* A-1300-292-A D BOARD COMPLETE (KV-DR29M39)
* A-1300-387-A D BOARD COMPLETE (KV-DR29M63)
* A-1300-405-A D BOARD COMPLETE
(KV-DR29M69/DR29M89)
**********************
* 4-363-146-00 HEAT SINK, V.OUT
* 4-374-846-01 COVER, CAPACITOR, CAP TYPE
4-382-854-11 SCREW (M3X10), P, SW (+)
4-382-854-21 SCREW (M3X14), P, SW (+)
<CAPACITOR>
C6100 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C6101 1-107-680-91 ELECT 22UF 20.00% 450V
C6102 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C6103 1-163-133-00 CERAMIC CHIP 470PF 5.00% 50V
C6104 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C6105 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C6106 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
C6107 1-137-605-11 MYLAR 0.01UF 10.00% 250V
C6108 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C6109 1-126-971-11 ELECT 470UF 20.00% 50V
C6110 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C6111 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C6113 1-126-965-91 ELECT 22UF 20.00% 50V
C6334 1-126-940-11 ELECT 330UF 20.00% 25V
C6600 1-128-550-11 ELECT 2200UF 20.00% 50V
C6601 1-126-967-11 ELECT 47UF 20.00% 50V
C6602 1-129-720-00 FILM 0.033UF 5.00% 630V
(KV-DR29M39/M63)
C6603 1-126-949-11 ELECT 220UF 20.00% 35V
C6604 1-126-967-11 ELECT 47UF 20.00% 50V
C6606 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
(KV-DR29M69/M89)
C6607 ! 1-119-892-51 CERAMIC 470PF 10.00% 250V
C6608 ! 1-119-892-51 CERAMIC 470PF 10.00% 250V
C6609 1-126-960-11 ELECT 1UF 20.00% 50V
(KV-DR29M69/M89)
C6110 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
(KV-DR29M69/M89)
C6611 1-115-416-11 CERAMIC CHIP 0.001UF 5.00% 25V
(KV-DR29M69/M89)
C6612 1-126-964-11 ELECT 10UF 20.00% 50V
(KV-DR29M39/M63)
C6613 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C6614 1-161-830-00 CERAMIC 0.0047UF 500V
C6615 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
(KV-DR29M39/M63)
C6616 1-126-961-11 ELECT 2.2UF 20.00% 50V
(KV-DR29M39/M63)
