– 130 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
C6617 1-161-830-00 CERAMIC 0.0047UF 500V
C6618 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 16V
(KV-DR29M39/M63)
C6619 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C6620 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 16V
C6621 1-131-940-11 ELECT 1200UF 20% 250V
(KV-DR29M69/M89)
C6622 1-131-940-11 ELECT 1200UF 20% 250V
(KV-DR29M69/M89)
C6624 1-126-966-11 ELECT 33UF 20.00% 50V
(KV-DR29M39/M63)
C6629 1-125-906-11 ELECT 560UF 20.00% 450V
(KV-DR29M39/M63)
C6633 1-136-479-11 FILM 0.001UF 2.00% 50V
C6634 1-126-964-11 ELECT 10UF 20.00% 50V
C6635 1-126-963-11 ELECT 4.7UF 20.00% 50V
C6637 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C6645 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C6647 1-126-964-11 ELECT 10UF 20.00% 50V
C6648 1-125-969-91 CERAMIC 680PF 10.00% 1KV
C6649 1-125-969-91 CERAMIC 680PF 10.00% 1KV
C6650 1-125-969-91 CERAMIC 680PF 10.00% 1KV
C6651 1-125-969-91 CERAMIC 680PF 10.00% 1KV
C6652 1-110-626-11 ELECT 330UF 20.00% 160V
C6653 1-136-287-11 MYLAR 0.0047UF 5.00% 50V
C6654 1-126-936-11 ELECT 3300UF 20.00% 16V
C6655 1-126-936-11 ELECT 3300UF 20.00% 16V
C6656 1-136-165-00 FILM 0.1UF 5.00% 50V
C6658 1-104-330-91 CERAMIC 470PF 10.00% 1KV
C6660 1-126-960-11 ELECT 1UF 20.00% 50V
C6661 1-126-947-11 ELECT 47UF 20.00% 16V
C6662 1-126-947-11 ELECT 47UF 20.00% 16V
C6665 1-126-964-11 ELECT 10UF 20.00% 50V
C6666 1-137-150-11 MYLAR 0.01UF 5.00% 50V
C6668 1-126-947-11 ELECT 47UF 20.00% 25V
C6669 1-125-969-91 CERAMIC 680PF 10.00% 1KV
C6670 1-125-969-91 CERAMIC 680PF 10.00% 1KV
C6672 1-135-946-21 FILM 47000PF 3% 800V
C6673 1-136-189-00 MYLAR 0.1UF 10.00% 250V
C6674 1-128-527-11 ELECT 330UF 20.00% 25V
C6679 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C6800 1-102-129-00 CERAMIC 0.01UF 10.00% 50V
C6801 1-126-947-11 ELECT 47UF 20.00% 16V
C6802 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C6805 1-111-087-11 ELECT 330UF 20.00% 25V
C6806 1-107-933-11 ELECT 100UF 20.00% 100V
C6808 1-137-401-11 MYLAR 0.22UF 10.00% 100V
C6809 1-102-074-00 CERAMIC 0.001UF 10.00% 50V
C6810 1-106-220-00 MYLAR 0.1UF 10.00% 100V
C6811 1-111-087-11 ELECT 330UF 20.00% 25V
C6813 1-126-935-11 ELECT 470UF 20.00% 16V
C6814 1-125-889-91 CERAMIC CHIP 2.2UF 10% 10V
C6816 1-136-060-00 FILM 0.047UF 5.00% 400V
C6818 1-126-960-11 ELECT 1UF 20.00% 50V
C6819 1-126-960-11 ELECT 1UF 20.00% 50V
C6820 1-102-114-00 CERAMIC 470PF 10.00% 50V
C6821 1-106-383-00 MYLAR 0.047UF 10.00% 200V
C6822 1-102-114-00 CERAMIC 470PF 10.00% 50V
C6823 1-106-383-00 MYLAR 0.047UF 10.00% 200V
C6826 1-102-030-00 CERAMIC 330PF 10.00% 500V
C6827 1-102-030-00 CERAMIC 330PF 10.00% 500V
C6829 1-162-134-11 CERAMIC 470PF 10.00% 2KV
C6831 1-117-835-11 FILM 6200PF 3.00% 1.5KV
C6832 1-117-836-11 FILM 6800PF 3.00% 1.5KV
C6836 1-127-681-11 FILM 10000PF 2% 100V
C6837 1-125-893-11 FILM 680PF 3.00% 1.5KV
C6838 1-125-893-11 FILM 680PF 3.00% 1.5KV
C6839 1-126-933-11 ELECT 100UF 20.00% 16V
C6840 1-126-933-11 ELECT 100UF 20.00% 16V
C6841 1-115-511-11 FILM 0.12UF 5.00% 250V
C6842 1-117-667-71 FILM 0.47UF 5.00% 250V
C6843 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C6844 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C6845 1-115-514-11 FILM 0.22UF 5.00% 250V
C6846 1-109-945-11 FILM 0.18UF 5.00% 250V
(KV-DR29M39/M63)
C6848 1-113-979-51 FILM 0.047UF 5% 250V
C6849 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C6850 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C6851 1-107-639-11 ELECT 47UF 20.00% 160V
C6853 1-102-228-00 CERAMIC 470PF 10.00% 500V
C6854 1-126-941-11 ELECT 470UF 20.00% 25V
C6855 1-123-024-21 ELECT 33UF 160V
C6856 1-126-971-11 ELECT 470UF 20.00% 50V
C6857 1-102-228-00 CERAMIC 470PF 10.00% 500V
C6858 1-102-228-00 CERAMIC 470PF 10.00% 500V
C6859 1-162-129-00 CERAMIC 150PF 10.00% 2KV
C6860 1-162-131-11 CERAMIC 220PF 10.00% 2KV
C6862 1-130-202-00 FILM 0.022UF 5.00% 200V
C6864 1-129-898-00 FILM 0.0022UF 5.00% 630V
C6865 1-130-202-00 FILM 0.022UF 5.00% 400V
C6866 1-102-030-00 CERAMIC 330PF 10.00% 500V
C6867 1-130-785-11 MYLAR 0.47UF 10.00% 100V
C6868 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C6879 1-107-960-11 ELECT 4.7UF 20.00% 160V
C6882 1-104-574-11 CERAMIC 0.0047UF 10.00% 2KV
C6884 1-125-889-91 CERAMIC CHIP 2.2UF 10% 10V
C6885 1-162-131-11 CERAMIC 220PF 10.00% 2KV
(KV-DR29M39/M63)
C6886 1-126-964-11 ELECT 10UF 20.00% 50V
C6888 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
<CONNECTOR>
CN6602 * 1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P
(KV-DR29M39/M69/M89)
CN6603 * 1-691-134-11 PIN, CONNECTOR (PC BOARD) 2P
(KV-DR29M39/M63)
CN6603 * 1-573-963-11 PIN, CONNECTOR (PC BOARD) 3P
(KV-DR29M69/M89)
CN6604 1-580-843-11 PIN, CONNECTOR (POWER)
CN6605 * 1-764-333-11 PLUG, CONNECTOR 10P
CN6606 * 1-764-333-11 PLUG, CONNECTOR 10P
CN6609 * 1-508-784-21 PIN, CONNECTOR (5MM PITCH) 1P
CN6610 * 1-508-784-21 PIN, CONNECTOR (5MM PITCH) 1P
CN6611 * 1-508-784-21 PIN, CONNECTOR (5MM PITCH) 1P
CN6612 * 1-508-784-21 PIN, CONNECTOR (5MM PITCH) 1P
CN6613 * 1-508-784-21 PIN, CONNECTOR (5MM PITCH) 1P
CN6614 * 1-508-784-21 PIN, CONNECTOR (5MM PITCH) 1P
CN6615 * 1-508-784-21 PIN, CONNECTOR (5MM PITCH) 1P
CN6616 * 1-508-784-21 PIN, CONNECTOR (5MM PITCH) 1P
CN6618 * 1-508-784-21 PIN, CONNECTOR (5MM PITCH) 1P
CN6619 1-564-507-41 PLUG, CONNECTOR 4P
CN6801 * 1-785-270-12 PIN, DY CONNECTOR (PC BOARD)
CN6802 * 1-764-333-11 PLUG, CONNECTOR 10P
D
