– 131 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
CN6803 1-793-495-11 CONNECTOR, BOARD TO BOARD 50P
CN6804 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
(KV-DR29M39/M63)
CN6805 1-695-915-11 TAB (CONTACT)
CN6806 1-764-334-11 PLUG, CONNECTOR 11P
CN6809 1-695-915-11 TAB (CONTACT)
CN6810 1-785-879-11 CONNECTOR, ONE TOUCH
CN6811 * 1-508-784-21 PIN, CONNECTOR (5MM PITCH) 1P
CN6812 * 1-508-784-21 PIN, CONNECTOR (5MM PITCH) 1P
<DIODE>
D6100 8-719-077-76 D2SB60A-F04
D6101 8-719-110-49 RD18ES-B2
D6102 8-719-082-03 DIODE MM3Z15VT1
D6103 8-719-081-97 MMDL914T1
D6104 8-719-510-48 D1N20R
D6105 8-719-948-45 ERA22-08
D6108 8-719-063-73 DIODE D1NL20U-TR
D6323 8-719-032-12 D1NS6
D6601 8-719-911-19 1SS119-25
D6602 8-719-081-97 MMDL914T1 (KV-DR29M69/M89)
D6603 8-719-081-97 MMDL914T1 (KV-DR29M69/M89)
D6604 8-719-081-97 MMDL914T1 (KV-DR29M69/M89)
D6605 8-719-510-53 D4SB60L
D6608 8-719-081-97 MMDL914T1
D6609 8-719-911-19 1SS119-25 (KV-DR29M69/M89)
D6610 8-719-081-97 MMDL914T1 (KV-DR29M69/M89)
D6611 8-719-081-97 MMDL914T1 (KV-DR29M69/M89)
D6612 8-719-911-55 U05G (KV-DR29M69/M89)
D6613 8-719-911-55 U05G (KV-DR29M69/M89)
D6614 8-719-110-30 RD12ES-B1
D6615 8-719-911-19 1SS119-25
D6618 8-719-979-64 UF4005PKG23
D6620 8-719-063-73 DIODE D1NL20U-TR
D6623 8-719-911-19 1SS119-25
D6631 8-719-050-18 D4SBL20U
D6632 8-719-081-97 MMDL914T1
D6633 8-719-510-12 D10SC4M
D6635 8-719-110-47 RD18ESB
D6636 8-719-911-19 1SS119-25
D6639 8-719-063-73 DIODE D1NL20U-TR
D6640 8-719-110-72 RD30ESB2
D6641 8-719-109-96 RD6.8ES-B1
D6642 8-719-911-19 1SS119-25
D6644 8-719-052-92 D10SBS4F
D6648 8-719-110-30 RD12ES-B1 (KV-DR29M69/M89)
D6654 8-719-052-92 D10SBS4F
D6802 8-719-911-19 1SS119-25
D6803 8-719-510-73 S3L20UF4
D6804 8-719-911-19 1SS119-25
D6806 8-719-911-19 1SS119-25
D6808 8-719-110-02 RD7.5ES-B1
D6812 8-719-110-39 RD15ES-B1
D6813 8-719-302-43 EL1Z
D6814 8-719-018-82 RGP02-20EL-6394
D6816 8-719-510-73 S3L20UF4
D6817 8-719-510-73 S3L20UF4
D6820 8-719-970-87 ERA38-06
D6821 8-719-970-87 ERA38-06
D6824 8-719-510-73 S3L20UF4
D6825 8-719-050-38 DIODE M1MA152WK-T1
D6830 8-719-988-61 1SS355TE-17
D6831 8-719-945-81 ERC06-15SA
<FERRITE BEAD>
FB6602 1-239-358-21 FILTER, NOISE
FB6603 1-239-358-21 FILTER, NOISE
FB6604 1-410-396-41 FERRITE 0.45UH
FB6605 1-410-396-41 FERRITE 0.45UH
FB6606 1-410-397-21 FERRITE 1.1UH
FB6607 1-410-396-41 FERRITE 0.45UH
FB6608 1-410-396-41 FERRITE 0.45UH
<IC>
IC6600 8-759-670-30 MCZ3001D
IC6601 8-759-198-31 UPC1093J-1-T (KV-DR29M39/M63)
IC6607 8-749-012-13 DM-58
IC6608 8-759-133-90 UPC339C (KV-DR29M39/M63)
IC6800 8-759-696-71 STV9379A
IC6804 8-759-394-36 BA09T
IC6805 8-759-394-35 BA12T
<CHIP CONDUCTOR>
JR6601 1-216-295-91 SHORT CHIP 0
JR6603 1-216-295-91 SHORT CHIP 0
JR6608 1-216-295-91 SHORT CHIP 0
JR6609 1-216-295-91 SHORT CHIP 0
JR6614 1-216-295-91 SHORT CHIP 0
JR6615 1-216-295-91 SHORT CHIP 0
JR6616 1-216-295-91 SHORT CHIP 0
<COIL>
L6604 1-412-525-31 INDUCTOR 10UH
L6605 1-412-525-31 INDUCTOR 10UH
L6606 1-412-525-31 INDUCTOR 10UH
L6607 1-412-519-11 INDUCTOR 3.3UH
L6608 1-412-525-31 INDUCTOR 10UH
L6800 1-412-525-31 INDUCTOR 10UH
L6801 1-406-675-11 INDUCTOR 4.7MH
L6803 1-406-985-11 INDUCTOR 2.2MH
L6804 1-412-519-11 INDUCTOR 3.3UH
L6805 1-412-519-11 INDUCTOR 3.3UH
L6806 1-412-519-11 INDUCTOR 3.3UH
L6807 1-412-552-11 INDUCTOR 2.2MH
L6808 1-406-674-11 INDUCTOR 3.3MH
<PHOTO COUPLER>
PH6601 ! 8-749-924-35 ON3171-R
PH6602 ! 8-749-924-35 ON3171-R
<IC LINK>
PS6605 1-533-597-41 LINK, IC
PS6606 1-533-597-41 LINK, IC
PS6609 1-533-597-41 LINK, IC
PS6801 1-532-841-21 LINK, IC
D
