– 132 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
<TRANSISTOR>
Q6100 8-729-046-40 2SK2663
Q6102 8-729-023-22 2SD2114K
Q6600 8-729-052-32 IRFIB7N50A
Q6601 8-729-119-78 2SC2785-HFE
Q6602 8-729-119-78 2SC2785-HFE (KV-DR29M69/M89)
Q6603 8-729-052-32 IRFIB7N50A
Q6604 8-729-119-76 2SA1175-HFE
Q6605 8-729-230-49 2SC2712-YG (KV-DR29M39/M63)
Q6608 8-729-200-21 2SC2500-B
Q6609 8-729-029-56 DTA144ESA
Q6610 8-729-119-78 2SC2785-HFE
Q6611 8-729-029-66 DTC114ESA
Q6613 8-729-030-02 DTC144ESA
Q6614 8-729-119-76 2SA1175-HFE (KV-DR29M39/M63)
Q6619 8-729-119-78 2SC2785-HFE
Q6620 8-729-119-78 2SC2785-HFE
Q6800 8-729-421-19 UN2213
Q6802 8-729-025-19 IRFI740G
Q6803 8-729-119-76 2SA1175-HFE
Q6804 8-729-119-78 2SC2785-HFE
Q6805 8-729-140-96 2SD774-34
Q6806 8-729-140-96 2SD774-34
Q6807 8-729-056-17 TRANSISTOR 2SC5696-SONY-CA
Q6808 8-729-056-16 TRANSISTOR 2SC5698-SONY-CA
Q6809 8-729-050-48 TRANSISTOR IRF614-005
Q6810 8-729-047-60 IRFI830G-LF49
Q6811 8-729-010-25 MSD601-RT1
Q6812 8-729-043-95 2SC3840(3)
Q6819 8-729-010-25 MSD601-RT1
Q6820 8-729-010-25 MSD601-RT1
Q6821 8-729-010-25 MSD601-RT1
<RESISTOR>
R6100 1-260-298-51 CARBON 3.3 5% 1/2W
R6101 1-216-045-00 RES-CHIP 680 5% 1/10W
R6102 1-249-389-11 CARBON 4.7 5% 1/4W
R6103 1-216-009-91 RES-CHIP 22 5% 1/10W
R6104 1-240-205-91 CARBON 22M 5% 1/2W
R6105 1-216-097-11 RES-CHIP 100K 5% 1/10W
R6106 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6107 1-216-089-91 RES-CHIP 47K 5% 1/10W
R6108 1-215-493-00 METAL 1M 1% 1/4W
R6110 1-249-413-11 CARBON 470 5% 1/4W
R6500 1-220-797-11 CEMENTED 0.47 5% 10W
R6600 1-216-295-91 SHORT CHIP 0
R6602 1-249-417-11 CARBON 1K 5% 1/4W
R6603 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
(KV-DR29M39/M63)
R6604 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
(KV-DR29M39/M63)
R6605 1-215-471-00 METAL 120K 1% 1/4W
(KV-DR29M69/M89)
R6606 1-215-466-00 METAL 75K 1% 1/4W
(KV-DR29M69/M89)
R6607 1-215-489-00 METAL 680K 1% 1/4W
(KV-DR29M69/M89)
R6608 1-215-489-00 METAL 680K 1% 1/4W
(KV-DR29M69/M89)
R6609 1-215-489-00 METAL 680K 1% 1/4W
(KV-DR29M69/M89)
R6610 1-208-830-11 METAL CHIP 100K 0.5% 1/10W
(KV-DR29M69/M89)
R6611 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
(KV-DR29M39/M63)
R6612 1-215-471-00 METAL 120K 1% 1/4W
(KV-DR29M69/M89)
R6613 1-215-489-00 METAL 680K 1% 1/4W
(KV-DR29M69/M89)
R6614 1-215-489-00 METAL 680K 1% 1/4W
(KV-DR29M69/M89)
R6615 1-215-489-00 METAL 680K 1% 1/4W
(KV-DR29M69/M89)
R6616 1-208-830-11 METAL CHIP 100K 0.5% 1/10W
(KV-DR29M69/M89)
R6617 1-218-909-11 METAL CHIP 390K 0.5% 1/10W
(KV-DR29M69/M89)
R6618 1-215-466-00 METAL 75K 1% 1/4W
(KV-DR29M69/M89)
R6619 1-216-853-11 RES-CHIP 470K 5% 1/10W
(KV-DR29M69/M89)
R6620 1-218-911-11 METAL CHIP 470K 0.5% 1/10W
(KV-DR29M69/M89)
R6621 1-216-073-91 RES-CHIP 10K 5% 1/10W
(KV-DR29M69/M89)
R6622 1-220-797-11 CEMENTED 0.47 5% 10W
R6623 1-215-864-00 METAL OXIDE 150 5% 1W
(KV-DR29M69/M89)
R6624 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
(KV-DR29M39/M63)
R6625 1-215-864-00 METAL OXIDE 150 5% 1W
R6626 1-215-444-00 METAL 9.1K 1% 1/4W
R6627 1-215-481-00 METAL 330K 1% 1/4W
R6628 1-216-833-11 RES-CHIP 10K 5% 1/10W
(KV-DR29M39/M63)
R6629 1-215-481-00 METAL 330K 1% 1/4W
R6630 1-215-481-00 METAL 330K 1% 1/4W
R6631 1-208-808-11 METAL CHIP 12K 0.5% 1/10W
R6632 1-208-758-11 METAL CHIP 100 0.5% 1/10W
R6633 1-215-458-00 METAL 36K 1% 1/4W
(KV-DR29M39/M63)
R6634 1-215-489-00 METAL 680K 1% 1/4W
(KV-DR29M39/M63)
R6635 1-215-489-00 METAL 680K 1% 1/4W
(KV-DR29M39/M63)
R6636 1-215-489-00 METAL 680K 1% 1/4W
(KV-DR29M39/M63)
R6637 1-215-463-00 METAL 56K 1% 1/4W
(KV-DR29M39/M63)
R6638 1-245-291-11 RES, CEMENT-COATED 2.2
(KV-DR29M39/M63)
R6638 1-240-876-11 CEMENTED 1 5% 15W
(KV-DR29M69/M89)
R6639 1-240-876-11 CEMENTED 1 5% 15W
(KV-DR29M69/M89)
R6640 1-216-081-00 RES-CHIP 22K 5% 1/10W
(KV-DR29M69/M89)
R6641 1-260-131-11 CARBON 470K 5% 1/2W
(KV-DR29M69/M89)
R6642 1-260-131-11 CARBON 470K 5% 1/2W
(KV-DR29M69/M89)
R6643 1-216-081-00 RES-CHIP 22K 5% 1/10W
(KV-DR29M69/M89)
R6644 1-249-417-11 CARBON 1K 5% 1/4W
R6645 1-220-886-11 FUSIBLE 0.1 10% 1W
R6647 1-216-639-11 METAL CHIP 330 0.5% 1/10W
D
