– 134 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
<RELAY>
RY6601! 1-755-198-12 RELAY
RY6602 1-755-357-11 RELAY, AC POWER (KV-DR29M69/M89)
RY6603 1-755-357-11 RELAY, AC POWER
<TRANSFORMER>
T6100 ! 1-433-844-11 TRANSFORMER, CONVERTER
T6602 ! 1-435-690-11 TRANSFORMER, CONVERTER (PIT)
T6800 1-429-741-11 TRANSFORMER, DRIVE
T6801 1-437-690-11 TRANSFORMER, FERRITE (DFT)
T6802 1-437-430-11 TRANSFORMER, FERRITE (HDT)
T6803 ! 1-453-325-12 TRANSFORMER ASSY FLY BACK
(NX-4522//M3B4)
T6804 1-437-430-11 TRANSFORMER, FERRITE (HDT)
<THERMISTOR>
TH6100 1-803-586-11 THERMISTOR, NTC
TH6601 1-803-540-11 THERMISTOR
TH6801 1-800-193-00 THERMISTOR
<VARISTOR>
VD6603 1-803-830-11 VARISTOR (ERZV14D621) (KV-DR29M39/M63)
****************************************************************
* A-1400-486-A D5 BOARD MOUNTED
(KV-DR29M39/DR29M69/DR29M89)
* A-1400-689-A D5 BOARD MOUNTED (KV-DR29M63)
**********************************
4-382-854-11 SCREW (M3X10), P, SW (+)
<CAPACITOR>
C6101 1-126-965-91 ELECT 22UF 20.00% 50V
C6102 1-126-965-91 ELECT 22UF 20.00% 50V
C6103 1-107-725-11 CERAMIC CHIP 0.1UF 10.00% 16V
C6104 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C6105 1-126-960-11 ELECT 1UF 20.00% 50V
C6106 1-136-347-11 FILM 0.0047UF 5.00% 630V
C6107 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6108 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6109 1-129-716-00 FILM 0.015UF 5.00% 630V
C6110 1-126-947-11 ELECT 47UF 20.00% 25V
C6111 1-136-165-00 FILM 0.1UF 5.00% 50V
C6114 1-107-725-11 CERAMIC CHIP 0.1UF 10.00% 16V
C6115 1-126-947-11 ELECT 47UF 20.00% 25V
C6116 1-136-479-11 FILM 0.001UF 2.00% 50V
C6117 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
C6118 1-107-725-11 CERAMIC CHIP 0.1UF 10.00% 16V
C6119 1-162-960-11 CERAMIC CHIP 220PF 10.00% 50V
C6201 1-163-133-00 CERAMIC CHIP 470PF 5.00% 50V
C6202 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C6203 1-163-133-00 CERAMIC CHIP 470PF 5.00% 50V
C6204 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
C6205 1-136-479-11 FILM 0.001UF 2.00% 50V
C6206 1-136-479-11 FILM 0.001UF 2.00% 50V
C6208 1-126-968-11 ELECT 100UF 20.00% 50V
C6209 1-104-663-11 ELECT 33UF 20.00% 25V
C6210 1-107-725-11 CERAMIC CHIP 0.1UF 10.00% 16V
C6213 1-126-965-91 ELECT 22UF 20.00% 50V
C6214 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6215 1-126-947-11 ELECT 47UF 20.00% 25V
C6216 1-104-760-11 CERAMIC CHIP 0.047UF 10.00% 50V
C6217 1-126-965-91 ELECT 22UF 20.00% 50V
C6218 1-126-947-11 ELECT 47UF 20.00% 25V
C6219 1-126-947-11 ELECT 47UF 20.00% 25V
C6220 1-107-725-11 CERAMIC CHIP 0.1UF 10.00% 16V
C6223 1-126-947-11 ELECT 47UF 20.00% 25V
C6227 1-107-725-11 CERAMIC CHIP 0.1UF 10.00% 16V
C6229 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6230 1-126-947-11 ELECT 47UF 20.00% 25V
C6233 1-126-964-11 ELECT 10UF 20.00% 50V
C6306 1-104-760-11 CERAMIC CHIP 0.047UF 10.00% 50V
C6402 1-163-133-00 CERAMIC CHIP 470PF 5.00% 50V
C6403 1-163-133-00 CERAMIC CHIP 470PF 5.00% 50V
C6404 1-115-416-11 CERAMIC CHIP 0.001UF 5.00% 25V
C6406 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6408 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C6409 1-126-947-11 ELECT 47UF 20.00% 25V
C6410 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6411 1-107-725-11 CERAMIC CHIP 0.1UF 10.00% 16V
C6412 1-126-947-11 ELECT 47UF 20.00% 25V
C6413 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6414 1-126-960-11 ELECT 1UF 20.00% 50V
C6416 1-126-934-11 ELECT 220UF 20.00% 16V
C6422 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
C6423 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6424 1-136-479-11 FILM 0.001UF 2.00% 50V
C6427 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C6428 1-163-259-91 CERAMIC CHIP 220PF 5.00% 50V
C6429 1-126-965-91 ELECT 22UF 20.00% 50V
C6430 1-104-760-11 CERAMIC CHIP 0.047UF 10.00% 50V
C6432 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C6433 1-126-960-11 ELECT 1UF 20.00% 50V
C6434 1-107-725-11 CERAMIC CHIP 0.1UF 10.00% 16V
C6436 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6437 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6441 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C6442 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C6443 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6444 1-136-479-11 FILM 0.001UF 2.00% 50V
C6445 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C6451 1-216-295-91 SHORT CHIP 0
C6452 1-104-760-11 CERAMIC CHIP 0.047UF 10.00% 50V
C6454 1-208-854-11 METAL CHIP 1M 0.5% 1/10W
C6458 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
C6459 1-115-340-11 CERAMIC CHIP 0.22UF 10.00% 25V
C6460 1-115-185-11 CERAMIC CHIP 0.033UF 10.00% 50V
C6505 1-126-947-11 ELECT 47UF 20.00% 25V
C6506 1-126-947-11 ELECT 47UF 20.00% 25V
C6508 1-136-495-11 FILM 0.068UF 5.00% 50V
C6510 1-126-947-11 ELECT 47UF 20.00% 25V
C6511 1-126-947-11 ELECT 47UF 20.00% 25V
C6512 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6513 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6514 1-126-964-11 ELECT 10UF 20.00% 50V
C6515 1-107-714-11 ELECT 10UF 20.00% 50V
C6516 1-104-760-11 CERAMIC CHIP 0.047UF 10.00% 50V
D5
