Sony TRINITRON KV-DR29M39 - Page 117

– 135 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
C6517 1-107-714-11 ELECT 10UF 20.00% 50V
C6518 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
<CONNECTOR>
CN6100 1-793-498-11 CONNECTOR, BOARD TO BOARD 50P
CN6101 * 1-564-523-11 PLUG, CONNECTOR 8P
CN6102 * 1-564-518-11 PLUG, CONNECTOR 3P
<DIODE>
D6102 8-719-987-87 ERA85-009
D6103 8-719-911-19 1SS119-25
D6104 8-719-911-19 1SS119-25
D6105 8-719-063-73 DIODE D1NL20U-TR
D6201 8-719-081-97 MMDL914T1
D6201 8-719-404-50 MA111-TX
D6202 8-719-081-97 MMDL914T1
D6203 8-719-081-97 MMDL914T1
D6204 8-719-081-97 MMDL914T1
D6207 1-218-851-11 METAL CHIP 1.5K 0.5% 1/10W
D6208 8-719-081-97 MMDL914T1
D6209 8-719-081-97 MMDL914T1
D6210 1-216-295-91 SHORT CHIP 0
D6211 1-216-295-91 SHORT CHIP 0
D6212 8-719-081-97 MMDL914T1
D6213 8-719-081-97 MMDL914T1
D6214 8-719-081-97 MMDL914T1
D6215 1-216-295-91 SHORT CHIP 0
D6216 1-216-295-91 SHORT CHIP 0
D6217 1-216-295-91 SHORT CHIP 0
D6218 1-216-295-91 SHORT CHIP 0
D6219 1-216-295-91 SHORT CHIP 0
D6401 8-719-081-97 MMDL914T1
D6402 8-719-081-97 MMDL914T1
D6403 8-719-081-97 MMDL914T1
D6404 1-216-295-91 SHORT CHIP 0
D6405 8-719-081-97 MMDL914T1
D6409 8-719-081-97 MMDL914T1
D6411 8-719-081-97 MMDL914T1
D6413 8-719-081-97 MMDL914T1
D6423 8-719-081-97 MMDL914T1
D6424 1-216-295-91 SHORT CHIP 0
D6425 8-719-988-61 1SS355TE-17
D6426 8-719-988-61 1SS355TE-17
D6427 8-719-988-61 1SS355TE-17
D6428 8-719-081-97 MMDL914T1
D6430 8-719-081-97 MMDL914T1
D6501 8-719-081-97 MMDL914T1
D6502 8-719-081-97 MMDL914T1
D6503 8-719-988-61 1SS355TE-17
D6504 8-719-988-61 1SS355TE-17
D6505 8-719-988-61 1SS355TE-17
<IC>
IC6100 6-701-598-01 IC UPC5023CS-184
IC6201 8-759-659-67 LA6393DLL
IC6202 8-759-231-53 TA7805S
IC6205 8-752-072-81 CXA1875AM
IC6206 8-759-700-69 NJM79L12A
IC6401 8-759-659-67 LA6393DLL
IC6402 6-701-847-01 IC UPC1898CT-A
IC6501 8-759-822-38 LA6510
<CHIP CONDUCTOR>
JR6100 1-216-295-91 SHORT CHIP 0
JR6101 1-216-295-91 SHORT CHIP 0
JR6102 1-216-295-91 SHORT CHIP 0
JR6103 1-216-295-91 SHORT CHIP 0
JR6200 1-216-295-91 SHORT CHIP 0
JR6201 1-216-295-91 SHORT CHIP 0
JR6202 1-216-295-91 SHORT CHIP 0
JR6204 1-216-295-91 SHORT CHIP 0
JR6401 1-216-295-91 SHORT CHIP 0
JR6402 1-216-295-91 SHORT CHIP 0
JR6403 1-216-295-91 SHORT CHIP 0
JR6404 1-216-295-91 SHORT CHIP 0
JR6405 1-216-295-91 SHORT CHIP 0
JR6406 1-216-295-91 SHORT CHIP 0
JR6407 1-216-295-91 SHORT CHIP 0
JR6408 1-216-295-91 SHORT CHIP 0
JR6409 1-216-295-91 SHORT CHIP 0
JR6410 1-216-295-91 SHORT CHIP 0
JR6411 1-216-295-91 SHORT CHIP 0
JR6413 1-216-295-91 SHORT CHIP 0
JR6414 1-216-295-91 SHORT CHIP 0
JR6416 1-216-295-91 SHORT CHIP 0
JR6417 1-216-295-91 SHORT CHIP 0
JR6418 1-216-295-91 SHORT CHIP 0
JR6420 1-216-295-91 SHORT CHIP 0
JR6421 1-216-295-91 SHORT CHIP 0
JR6422 1-216-295-91 SHORT CHIP 0
JR6423 1-216-295-91 SHORT CHIP 0
JR6424 1-216-295-91 SHORT CHIP 0
JR6425 1-216-295-91 SHORT CHIP 0
JR6426 1-216-295-91 SHORT CHIP 0
<COIL>
L6101 1-416-920-11 INDUCTOR 10MH
L6102 1-406-989-21 INDUCTOR 10MH
L6201 1-412-537-31 INDUCTOR 100UH
<TRANSISTOR>
Q6001 1-801-806-11 TR DTC144EKA (KV-DR29M39/M69/M89)
Q6001 8-729-421-19 UN2213 (KV-DR29M63)
Q6002 8-729-422-33 2SD601A-Q-TX (KV-DR29M39/M69/M89)
Q6002 8-729-010-25 MSD601-RT1 (KV-DR29M63)
Q6103 8-729-140-93 2SB733-34
Q6104 8-729-046-33 IRF720-LF49
Q6105 8-729-216-22 2SA1162-G
Q6106 8-729-010-25 MSD601-RT1
Q6107 8-729-804-87 2SB1142-T
Q6108 8-729-010-25 MSD601-RT1
Q6201 8-729-010-25 MSD601-RT1
Q6202 8-729-010-25 MSD601-RT1
Q6203 8-729-010-25 MSD601-RT1
Q6205 8-729-010-25 MSD601-RT1
Q6206 8-729-010-05 MSB709-RT1
