– 136 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
Q6207 8-729-421-19 UN2213
Q6208 8-729-216-22 2SA1162-G
Q6209 8-729-010-05 MSB709-RT1
Q6212 8-729-216-22 2SA1162-G
Q6213 8-729-010-25 MSD601-RT1
Q6215 8-729-010-25 MSD601-RT1
Q6216 8-729-216-22 2SA1162-G
Q6218 8-729-010-25 MSD601-RT1
Q6219 8-729-422-33 2SD601A-Q-TX (KV-DR29M39/M69/M89)
Q6219 8-729-010-25 MSD601-RT1 (KV-DR29M63)
Q6220 8-729-010-25 MSD601-RT1
Q6221 8-729-010-25 MSD601-RT1
Q6222 8-729-216-22 2SA1162-G
Q6401 8-729-010-25 MSD601-RT1
Q6402 8-729-216-22 2SA1162-G
Q6409 8-729-216-22 2SA1162-G
Q6410 8-729-010-25 MSD601-RT1
Q6412 8-729-216-22 2SA1162-G
Q6413 8-729-010-25 MSD601-RT1
Q6414 8-729-216-22 2SA1162-G
Q6415 8-729-010-25 MSD601-RT1
Q6417 8-729-010-25 MSD601-RT1
Q6418 8-729-216-22 2SA1162-G
Q6420 8-729-216-22 2SA1162-G
Q6422 8-729-216-22 2SA1162-G
Q6423 8-729-216-22 2SA1162-G
Q6424 8-729-010-25 MSD601-RT1
Q6425 8-729-010-25 MSD601-RT1
Q6437 8-729-010-25 MSD601-RT1
Q6438 8-729-216-22 2SA1162-G
Q6440 8-729-422-33 2SD601A-Q-TX (KV-DR29M39/M69/M89)
Q6440 8-729-010-25 MSD601-RT1 (KV-DR29M63)
Q6441 8-729-216-22 2SA1162-G
Q6501 8-729-216-22 2SA1162-G
Q6502 8-729-216-22 2SA1162-G
Q6503 8-729-010-25 MSD601-RT1
Q6504 8-729-010-25 MSD601-RT1
Q6505 8-729-010-25 MSD601-RT1
Q6506 8-729-421-22 UN2211
Q6507 8-729-421-22 UN2211
Q6508 8-729-422-33 2SD601A-Q-TX (KV-DR29M39/M69/M89)
Q6508 8-729-010-25 MSD601-RT1 (KV-DR29M63)
Q6509 8-729-010-25 MSD601-RT1
Q6510 8-729-216-22 2SA1162-G
<RESISTOR>
R6001 1-216-049-11 RES-CHIP 1K 5% 1/10W
R6002 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6003 1-216-025-11 RES-CHIP 100 5% 1/10W
R6006 1-216-089-91 RES-CHIP 47K 5% 1/10W
R6007 1-216-097-11 RES-CHIP 100K 5% 1/10W
R6102 1-216-049-11 RES-CHIP 1K 5% 1/10W
R6104 1-216-049-11 RES-CHIP 1K 5% 1/10W
R6107 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R6108 1-208-796-11 METAL CHIP 3.9K 0.5% 1/10W
R6109 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6111 1-208-808-11 METAL CHIP 12K 0.5% 1/10W
R6112 1-208-806-11 METAL CHIP 10K 0.5% 1/10W
R6113 1-208-806-11 METAL CHIP 10K 0.5% 1/10W
R6114 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W
R6115 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6116 1-216-049-11 RES-CHIP 1K 5% 1/10W
R6117 1-208-778-11 METAL CHIP 680 0.5% 1/10W
R6118 1-208-806-11 METAL CHIP 10K 0.5% 1/10W
R6119 1-216-025-11 RES-CHIP 100 5% 1/10W
R6120 1-208-818-11 METAL CHIP 33K 0.5% 1/10W
R6121 1-216-041-00 RES-CHIP 470 5% 1/10W
R6122 1-215-860-11 METAL OXIDE 33 5% 1W
R6127 1-216-025-11 RES-CHIP 100 5% 1/10W
R6128 1-208-792-11 METAL CHIP 2.7K 0.5% 1/10W
R6129 1-208-776-11 METAL CHIP 560 0.5% 1/10W
R6130 1-208-814-91 METAL CHIP 22K 0.5% 1/10W
R6131 1-208-812-11 METAL CHIP 18K 0.5% 1/10W
R6132 1-216-025-11 RES-CHIP 100 5% 1/10W
R6133 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R6136 1-208-814-91 METAL CHIP 22K 0.5% 1/10W
R6137 1-208-814-91 METAL CHIP 22K 0.5% 1/10W
R6138 1-208-788-11 METAL CHIP 1.8K 0.5% 1/10W
R6140 1-216-025-11 RES-CHIP 100 5% 1/10W
R6141 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6142 1-208-792-11 METAL CHIP 2.7K 0.5% 1/10W
R6143 1-216-073-91 RES-CHIP 10K 5% 1/10W
R6148 1-208-820-11 METAL CHIP 39K 0.5% 1/10W
R6201 1-216-073-91 RES-CHIP 10K 5% 1/10W
R6203 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6204 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R6205 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6206 1-216-073-91 RES-CHIP 10K 5% 1/10W
R6207 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6208 1-216-639-11 METAL CHIP 330 0.5% 1/10W
R6209 1-216-037-00 RES-CHIP 330 5% 1/10W
R6210 1-208-812-11 METAL CHIP 18K 0.5% 1/10W
R6213 1-208-818-11 METAL CHIP 33K 0.5% 1/10W
R6215 1-208-814-91 METAL CHIP 22K 0.5% 1/10W
R6216 1-216-089-91 RES-CHIP 47K 5% 1/10W
R6217 1-216-295-91 SHORT CHIP 0
R6218 1-216-125-00 RES-CHIP 1.5M 5% 1/10W
R6219 1-208-830-11 METAL CHIP 100K 0.5% 1/10W
R6220 1-216-089-91 RES-CHIP 47K 5% 1/10W
R6221 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R6222 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6224 1-216-085-91 RES-CHIP 33K 5% 1/10W
R6225 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6227 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6230 1-208-846-11 METAL CHIP 470K 0.5% 1/10W
R6232 1-208-814-91 METAL CHIP 22K 0.5% 1/10W
R6234 1-216-097-11 RES-CHIP 100K 5% 1/10W
R6237 1-249-377-11 CARBON 0.47 5% 1/4W
R6248 1-208-814-91 METAL CHIP 22K 0.5% 1/10W
R6249 1-208-804-11 METAL CHIP 8.2K 0.5% 1/10W
R6250 1-208-814-91 METAL CHIP 22K 0.5% 1/10W
R6253 1-216-025-11 RES-CHIP 100 5% 1/10W
R6254 1-216-025-11 RES-CHIP 100 5% 1/10W
R6255 1-216-025-11 RES-CHIP 100 5% 1/10W
R6256 1-216-025-11 RES-CHIP 100 5% 1/10W
R6266 1-216-017-91 RES-CHIP 47 5% 1/10W
R6267 1-216-017-91 RES-CHIP 47 5% 1/10W
R6270 1-208-814-91 METAL CHIP 22K 0.5% 1/10W
R6271 1-218-760-11 METAL CHIP 220K 0.5% 1/10W
R6272 1-216-049-11 RES-CHIP 1K 5% 1/10W
R6273 1-216-049-11 RES-CHIP 1K 5% 1/10W
R6274 1-249-377-11 CARBON 0.47 5% 1/4W
R6278 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
