– 138 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
R6540 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R6541 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6542 1-208-812-11 METAL CHIP 18K 0.5% 1/10W
R6543 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R6544 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6545 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6546 1-216-073-91 RES-CHIP 10K 5% 1/10W
R6551 1-216-073-91 RES-CHIP 10K 5% 1/10W
R6552 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6553 1-216-077-91 RES-CHIP 15K 5% 1/10W
R6554 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6555 1-208-806-11 METAL CHIP 10K 0.5% 1/10W
R6557 1-208-814-91 METAL CHIP 22K 0.5% 1/10W
R6558 1-208-826-11 METAL CHIP 68K 0.5% 1/10W
R6602 1-216-295-91 SHORT CHIP 0
R6604 1-208-850-11 METAL CHIP 680K 0.5% 1/10W
R6608 1-208-830-11 METAL CHIP 100K 0.5% 1/10W
R6609 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W
R6610 1-216-073-91 RES-CHIP 10K 5% 1/10W
R6611 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R6612 1-216-295-91 SHORT CHIP 0
R6614 1-216-295-91 SHORT CHIP 0
R6618 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
R6620 1-216-295-91 SHORT CHIP 0
***************************************************************
* A-1400-490-A F1 BOARD MOUNTED (KV-DR29M39)
* A-1400-691-A F1 BOARD MOUNTED (KV-DR29M63)
* A-1400-746-A F1 BOARD MOUNTED
(KV-DR29M69/DR29M89)
**********************
1-533-223-11 HOLDER, FUSE
* 4-374-846-01 COVER, CAPACITOR, CAP TYPE
<CAPACITOR>
C1601 ! 1-104-708-51 MYLAR 0.47UF 20.00% 250V
C1602 ! 1-109-835-51 MYLAR 0.68UF 20.00% 250V
C1603 ! 1-117-703-51 CERAMIC 0.0047UF 99% 250V
<CONNECTOR>
CN1601 1-580-843-11 PIN, CONNECTOR (POWER)
CN1602 1-580-843-11 PIN, CONNECTOR (POWER)
CN1604 1-695-915-11 TAB (CONTACT)
<FUSE>
F1601 ! 1-576-334-11 FUSE, CYLINDERICAL (TIME-LAG)
<FERRITE BEAD>
FB1601 1-410-397-21 FERRITE 1.1UH
FB1602 1-410-397-21 FERRITE 1.1UH
FB1603 1-410-397-21 FERRITE 1.1UH
FB1604 1-410-397-21 FERRITE 1.1UH
<RESISTOR>
R1601 ! 1-219-759-91 CARBON 1M 5% 1/2W
<TRANSFORMER>
T1601 ! 1-433-900-21 TRANSFORMER, LINE FILTER
T1602 ! 1-433-900-21 TRANSFORMER, LINE FILTER
<VARISTOR>
VDR161 1-803-830-11 VARISTOR (ERZV14D621)
***************************************************************
* A-1400-491-A H1 BOARD MOUNTED
(KV-DR29M39/DR29M69/DR29M89)
* A-1400-692-A H1 BOARD MOUNTED (KV-DR29M63)
*********************
<CAPACITOR>
C1910 1-126-947-11 ELECT 47UF 20.00% 16V
C1930 1-136-153-00 FILM 0.01UF 5.00% 50V
C1932 1-136-153-00 FILM 0.01UF 5.00% 50V
C1935 1-102-824-00 CERAMIC 470PF 5.00% 50V
C1938 1-102-824-00 CERAMIC 470PF 5.00% 50V
<CONNECTOR>
CN1905 * 1-764-333-11 PLUG, CONNECTOR 10P
CN1906 1-564-509-11 PLUG, CONNECTOR 6P
CN1932 * 1-564-509-11 PLUG, CONNECTOR 6P
CN1934 * 1-764-333-11 PLUG, CONNECTOR 10P
<DIODE>
D1905 8-719-070-16 NNCD9.1A-T1
D1907 8-719-070-16 NNCD9.1A-T1
D1930 8-719-929-15 HZS9.1NB2
D1944 8-719-070-16 NNCD9.1A-T1
D1945 8-719-911-19 1SS119-25
D1946 8-719-911-19 1SS119-25
<JACK>
J1931 1-770-786-11 JACK
J1932 1-784-646-11 TERMINAL, S
J1933 1-770-329-11 JACK, PIN 3P
<COIL>
L1931 1-414-856-11 INDUCTOR 10UH
L1932 1-414-856-11 INDUCTOR 10UH
<TRANSISTOR>
Q1901 8-729-030-02 DTC144ESA
Q1902 8-729-030-02 DTC144ESA
D5F1H1
