Sony TRINITRON KV-DR29M39 - Page 121

– 139 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
<RESISTOR>
R1911 1-249-411-11 CARBON 330 5% 1/4W
R1913 1-249-429-11 CARBON 10K 5% 1/4W
R1914 1-249-411-11 CARBON 330 5% 1/4W
R1915 1-249-429-11 CARBON 10K 5% 1/4W
R1916 1-249-401-11 CARBON 47 5% 1/4W
R1917 1-247-807-31 CARBON 100 5% 1/4W
R1920 1-247-807-31 CARBON 100 5% 1/4W
R1921 1-247-807-31 CARBON 100 5% 1/4W
R1933 1-247-895-91 CARBON 470K 5% 1/4W
R1934 1-247-807-31 CARBON 100 5% 1/4W
R1935 1-247-807-31 CARBON 100 5% 1/4W
R1936 1-247-895-91 CARBON 470K 5% 1/4W
R1952 1-249-421-11 CARBON 2.2K 5% 1/4W
R1970 1-249-426-11 CARBON 5.6K 5% 1/4W
R1971 1-249-413-11 CARBON 470 5% 1/4W
R1972 1-249-417-11 CARBON 1K 5% 1/4W
R1973 1-249-420-11 CARBON 1.8K 5% 1/4W
R1974 1-247-843-11 CARBON 3.3K 5% 1/4W
<SWITCH>
S1972 1-692-431-21 SWITCH, TACTILE
S1973 1-692-431-21 SWITCH, TACTILE
S1974 1-692-431-21 SWITCH, TACTILE
S1975 1-692-431-21 SWITCH, TACTILE
S1976 1-692-431-21 SWITCH, TACTILE
S1977 1-692-431-21 SWITCH, TACTILE
S1978 1-692-431-21 SWITCH, TACTILE
**************************************************************
* A-1400-492-A H2 BOARD MOUNTED
(KV-DR29M39//DR29M69/DR29M89)
* A-1400-693-A H2 BOARD MOUNTED (KV-DR29M63)
**********************************
* 4-055-304-01 HOLDER, LED
<CAPACITOR>
C1911 1-126-947-11 ELECT 47UF 20.00% 16V
C1912 1-102-824-00 CERAMIC 470PF 5.00% 50V
<CONNECTOR>
CN1651 * 1-580-844-11 PIN, CONNECTOR (POWER)
CN1652 * 1-580-844-11 PIN, CONNECTOR (POWER)
CN1907 * 1-564-521-11 PLUG, CONNECTOR 6P
<DIODE>
D1906 8-719-083-18 DIODE SPB-25MVWF
<IC>
IC1901 8-742-134-01 SBX1981-51RP
<SWITCH>
S1651 ! 1-571-433-31 SWITCH, PUSH (AC POWER)
*************************************************************
* A-1400-500-A J BOARD MOUNTED
(KV-DR29M39/DR29M69/DR29M89)
* A-1400-695-A J BOARD MOUNTED (KV-DR29M63)
********************************
<CAPACITOR>
C2410 1-126-967-11 ELECT 47UF 20.00% 50V
C2411 1-126-967-11 ELECT 47UF 20.00% 50V
C2412 1-126-967-11 ELECT 47UF 20.00% 50V
C2413 1-102-112-00 CERAMIC 330PF 10.00% 50V
C2414 1-102-112-00 CERAMIC 330PF 10.00% 50V
C2418 1-126-960-11 ELECT 1UF 20.00% 50V
C2419 1-126-960-11 ELECT 1UF 20.00% 50V
<CONNECTOR>
CN2410 * 1-564-523-11 PLUG, CONNECTOR 8P
<DIODE>
D2410 8-719-929-15 HZS9.1NB2
D2411 8-719-929-15 HZS9.1NB2
D2412 8-719-929-15 HZS9.1NB2
D2414 8-719-929-15 HZS9.1NB2
D2415 8-719-929-15 HZS9.1NB2
<JACK>
J2410 1-784-623-11 BLOCK, PIN JACK 5P
<RESISTOR>
R2410 1-247-804-11 CARBON 75 5% 1/4W
R2411 1-247-804-11 CARBON 75 5% 1/4W
R2412 1-247-804-11 CARBON 75 5% 1/4W
R2414 1-247-887-00 CARBON 220K 5% 1/4W
R2415 1-247-807-31 CARBON 100 5% 1/4W
R2417 1-247-887-00 CARBON 220K 5% 1/4W
R2418 1-247-807-31 CARBON 100 5% 1/4W
*************************************************************
* A-1300-299-A P BOARD COMPLETE
(KV-DR29M39/DR29M69/DR29M89)
********************************
<CAPACITOR>
C8801 1-104-665-11 ELECT 100UF 20.00% 10V
C8802 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8803 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
C8804 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
C8805 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
J
H1
H2
P
