– 140 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
C8806 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8807 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8808 1-126-967-11 ELECT 47UF 20.00% 50V
C8809 1-126-967-11 ELECT 47UF 20.00% 50V
C8810 1-104-665-11 ELECT 100UF 20.00% 10V
C8811 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8812 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8813 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8814 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8815 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8816 1-104-665-11 ELECT 100UF 20.00% 10V
C8817 1-104-665-11 ELECT 100UF 20.00% 10V
C8818 1-104-665-11 ELECT 100UF 20.00% 10V
C8819 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8820 1-104-665-11 ELECT 100UF 20.00% 10V
C8821 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8822 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8823 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8824 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C8825 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C8826 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8827 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8828 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8829 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8830 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8831 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8832 1-162-926-11 CERAMIC CHIP 82PF 5.00% 50V
C8834 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8835 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
<CONNECTOR>
CN8801 1-793-496-11 CONNECTOR, BOARD TO BOARD 20P
<DIODE>
D8801 8-719-081-97 MMDL914T1
<FILTER>
FL8802 1-236-071-11 ENCAPSULATED COMPONENT
FL8803 1-236-071-11 ENCAPSULATED COMPONENT
FL8804 1-236-071-11 ENCAPSULATED COMPONENT
FL8805 1-236-071-11 ENCAPSULATED COMPONENT
FL8808 1-236-071-11 ENCAPSULATED COMPONENT
<IC>
IC8801 8-759-830-24 SDA9588XB23
IC8802 8-759-460-72 BA033FP-E2
<COIL>
L8801 1-414-856-11 INDUCTOR 10UH
L8806 1-412-537-31 INDUCTOR 100UH
L8807 1-414-856-11 INDUCTOR 10UH
L8809 1-408-412-00 INDUCTOR 18UH
<TRANSISTOR>
Q8801 8-729-010-05 MSB709-RT1
Q8802 8-729-010-05 MSB709-RT1
Q8803 8-729-010-05 MSB709-RT1
Q8804 8-729-010-05 MSB709-RT1
Q8805 8-729-010-05 MSB709-RT1
Q8806 8-729-230-49 2SC2712-YG
Q8807 8-729-230-49 2SC2712-YG
Q8808 8-729-010-05 MSB709-RT1
Q8809 8-729-010-05 MSB709-RT1
Q8810 8-729-010-05 MSB709-RT1
Q8811 8-729-010-05 MSB709-RT1
Q8812 8-729-230-49 2SC2712-YG
<RESISTOR>
R8801 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8802 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8803 1-216-025-11 RES-CHIP 100 5% 1/10W
R8804 1-216-025-11 RES-CHIP 100 5% 1/10W
R8805 1-216-295-91 SHORT CHIP 0
R8806 1-216-041-00 RES-CHIP 470 5% 1/10W
R8807 1-216-041-00 RES-CHIP 470 5% 1/10W
R8808 1-216-041-00 RES-CHIP 470 5% 1/10W
R8809 1-216-025-11 RES-CHIP 100 5% 1/10W
R8810 1-216-025-11 RES-CHIP 100 5% 1/10W
R8811 1-216-639-11 METAL CHIP 330 0.5% 1/10W
R8812 1-216-025-11 RES-CHIP 100 5% 1/10W
R8815 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8816 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8817 1-216-041-00 RES-CHIP 470 5% 1/10W
R8818 1-216-025-11 RES-CHIP 100 5% 1/10W
R8819 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8820 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8821 1-216-025-11 RES-CHIP 100 5% 1/10W
R8822 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8823 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8824 1-216-025-11 RES-CHIP 100 5% 1/10W
R8825 1-216-041-00 RES-CHIP 470 5% 1/10W
R8826 1-216-025-11 RES-CHIP 100 5% 1/10W
R8827 1-216-025-11 RES-CHIP 100 5% 1/10W
R8828 1-216-025-11 RES-CHIP 100 5% 1/10W
R8829 1-216-025-11 RES-CHIP 100 5% 1/10W
R8830 1-216-025-11 RES-CHIP 100 5% 1/10W
R8831 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8832 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8833 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8834 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8835 1-216-047-91 RES-CHIP 820 5% 1/10W
R8836 1-216-047-91 RES-CHIP 820 5% 1/10W
R8837 1-216-025-11 RES-CHIP 100 5% 1/10W
R8838 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R8839 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R8840 1-216-025-11 RES-CHIP 100 5% 1/10W
R8841 1-216-025-11 RES-CHIP 100 5% 1/10W
R8842 1-216-097-11 RES-CHIP 100K 5% 1/10W
R8843 1-216-041-00 RES-CHIP 470 5% 1/10W
R8844 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8845 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8846 1-216-041-00 RES-CHIP 470 5% 1/10W
R8847 1-216-121-11 RES-CHIP 1M 5% 1/10W
R8848 1-216-073-91 RES-CHIP 10K 5% 1/10W
R8849 1-216-049-11 RES-CHIP 1K 5% 1/10W
R8850 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
