Sony TRINITRON KV-DR29M39 - Page 123

– 141 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
<CRYSTAL>
X8801 1-781-946-21 VIBRATOR, CRYSTAL
**************************************************************
A-1400-711-A V2 BOARD MOUNTED
(KV-DR29M39/DR29M69/DR29M89)
*******************************
<CAPACITOR>
C5802 1-164-360-11 CERAMIC CHIP 0.1UF 16V
C5805 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C5806 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C5815 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C5816 1-126-963-11 ELECT 4.7UF 20.00% 50V
C5817 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C5818 1-162-924-11 CERAMIC CHIP 56PF 5.00% 50V
C5820 1-162-924-11 CERAMIC CHIP 56PF 5.00% 50V
C5821 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C5822 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C5823 1-126-963-11 ELECT 4.7UF 20.00% 50V
C5826 1-126-963-11 ELECT 4.7UF 20.00% 50V
C5830 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C5831 1-126-933-11 ELECT 100UF 20.00% 16V
C5835 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C5837 1-126-933-11 ELECT 100UF 20.00% 16V
C5852 1-162-995-11 CERAMIC CHIP 0.022UF 50V
C5853 1-126-963-11 ELECT 4.7UF 20.00% 50V
<CONNECTOR>
CN5801 * 1-774-812-11 CONNECTOR, BOARD TO BOARD 7P
CN5803 * 1-774-812-11 CONNECTOR, BOARD TO BOARD 7P
<DIODE>
D5802 8-719-050-37 DIODE M1MA152WA-T1
D5803 8-719-045-99 RD2.2M-T1B
<FERRITE BEAD>
FB5801 1-410-397-21 FERRITE 1.1UH
FB5803 1-410-397-21 FERRITE 1.1UH
FB5804 1-410-397-21 FERRITE 1.1UH
FB5805 1-410-397-21 FERRITE 1.1UH
<IC>
IC5801 6-700-607-01 IC SAA5264PS/M3
IC5802 8-759-828-44 NJM2870F33(TE2)
<CHIP CONDUCTOR>
JR5802 1-216-295-91 SHORT CHIP 0
JR5803 1-216-295-91 SHORT CHIP 0
JR5804 1-216-295-91 SHORT CHIP 0
JR5805 1-216-295-91 SHORT CHIP 0
JR5811 1-216-041-00 RES-CHIP 470 5% 1/10W
JR5812 1-216-041-00 RES-CHIP 470 5% 1/10W
JR5813 1-216-041-00 RES-CHIP 470 5% 1/10W
<TRANSISTOR>
Q5801 8-729-230-49 2SC2712-YG
Q5803 8-729-230-49 2SC2712-YG
Q5810 8-729-230-49 2SC2712-YG
<RESISTOR>
R5821 1-216-082-00 RES-CHIP 24K 5% 1/10W
R5822 1-216-025-11 RES-CHIP 100 5% 1/10W
R5828 1-216-025-11 RES-CHIP 100 5% 1/10W
R5829 1-216-025-11 RES-CHIP 100 5% 1/10W
R5830 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R5831 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R5839 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R5841 1-216-025-11 RES-CHIP 100 5% 1/10W
R5842 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R5843 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R5845 1-216-049-11 RES-CHIP 1K 5% 1/10W
R5846 1-216-049-11 RES-CHIP 1K 5% 1/10W
R5851 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R5853 1-216-830-11 RES-CHIP 5.6K 5% 1/10W
R5857 1-216-081-00 RES-CHIP 22K 5% 1/10W
R5859 1-216-029-00 RES-CHIP 150 5% 1/10W
R5860 1-216-029-00 RES-CHIP 150 5% 1/10W
R5862 1-216-029-00 RES-CHIP 150 5% 1/10W
R5864 1-216-041-00 RES-CHIP 470 5% 1/10W
R5866 1-216-449-11 METAL OXIDE 56 5% 2W
R5871 1-216-037-00 RES-CHIP 330 5% 1/10W
R5878 1-216-073-91 RES-CHIP 10K 5% 1/10W
R5884 1-216-295-91 SHORT CHIP 0
R5892 1-216-025-11 RES-CHIP 100 5% 1/10W
R5899 1-216-025-11 RES-CHIP 100 5% 1/10W
<CRYSTAL>
X5801 1-578-774-11 VIBRATOR, CRYSTAL
***************************************************************
A-1400-499-A VM BOARD MOUNTED
(KV-DR29M39/DR29M69/DR29M89)
A-1400-694-A VM BOARD MOUNTED (KV-DR29M63)
*********************
4-382-854-11 SCREW (M3X10), P, SW (+)
<CAPACITOR>
C5401 1-126-935-11 ELECT 470UF 20.00% 16V
C5402 1-113-619-11 CERAMIC CHIP 0.47UF 10V
C5403 1-126-935-11 ELECT 470UF 20.00% 6.3V
C5405 1-126-933-11 ELECT 100UF 20.00% 16V
C5406 1-126-935-11 ELECT 470UF 20.00% 6.3V
C5407 1-107-364-11 MYLAR 0.01UF 10.00% 200V
C5408 1-107-364-11 MYLAR 0.01UF 10.00% 200V
C5409 1-107-649-11 ELECT 2.2UF 20.00% 250V
C5410 1-130-471-00 MYLAR 0.001UF 5.00% 50V
C5411 1-130-471-00 MYLAR 0.001UF 5.00% 50V
P V2 VM
