– 142 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
C5412 1-126-935-11 ELECT 470UF 20.00% 16V
C5413 1-107-648-91 ELECT 100UF 20.00% 160V
C5415 1-104-999-11 MYLAR 0.1UF 10.00% 200V
C5417 1-101-821-00 CERAMIC 0.0022UF 500V
C5418 1-107-638-11 ELECT 33UF 20.00% 160V
<CONNECTOR>
CN5401 * 1-770-723-11 CONNECTOR, BOARD TO BOARD 8P
CN5402 1-764-334-11 PLUG, CONNECTOR 11P
<DIODE>
D5400 8-719-404-50 MA111-TX
D5401 8-719-510-02 D1NS4 (KV-DR29M39/M69/M89)
D5401 8-719-210-21 11EQS04 (KV-DR29M63)
D5402 8-719-911-19 1SS119-25 (KV-DR29M39/M69/M89)
D5402 8-719-991-33 1SS133T-77 (KV-DR29M63)
D5403 8-719-911-19 1SS119-25 (KV-DR29M39/M69/M89)
D5403 8-719-991-33 1SS133T-77 (KV-DR29M63)
D5404 8-719-911-19 1SS119-25 (KV-DR29M39/M69/M89)
D5404 8-719-991-33 1SS133T-77 (KV-DR29M63)
D5405 8-719-110-56 RD22ES-B1
D5406 8-719-110-56 RD22ES-B1
<COIL>
L5400 1-412-525-31 INDUCTOR 10UH
<FILTER>
LP5401 * 4-042-408-01 PIN, COATING LEAD
<TRANSISTOR>
Q5400 8-729-119-78 2SC2785-HFE
Q5401 8-729-119-78 2SC2785-HFE
Q5402 8-729-119-78 2SC2785-HFE
Q5403 8-729-119-78 2SC2785-HFE
Q5404 8-729-119-76 2SA1175-HFE
Q5405 8-729-119-76 2SA1175-HFE
Q5406 8-729-045-05 2SA2005
Q5407 8-729-045-04 2SC5511
<RESISTOR>
R5401 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R5402 1-249-415-11 CARBON 680 5% 1/4W
R5403 1-247-739-11 CARBON 100 5% 1/2W
R5404 1-249-418-11 CARBON 1.2K 5% 1/4W
R5405 1-216-864-11 SHORT CHIP 0
R5406 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R5407 1-249-401-11 CARBON 47 5% 1/4W
R5408 1-247-807-31 CARBON 100 5% 1/4W
R5409 1-249-409-11 CARBON 220 5% 1/4W
R5410 1-249-401-11 CARBON 47 5% 1/4W
R5411 1-249-401-11 CARBON 47 5% 1/4W
R5412 1-249-429-11 CARBON 10K 5% 1/4W
R5413 1-249-414-11 CARBON 560 5% 1/4W
R5414 1-249-432-11 CARBON 18K 5% 1/4W
R5415 1-247-739-11 CARBON 100 5% 1/2W
R5416 1-249-385-11 CARBON 2.2 5% 1/4W
R5417 1-249-432-11 CARBON 18K 5% 1/4W
R5418 1-249-414-11 CARBON 560 5% 1/4W
R5419 1-249-421-11 CARBON 2.2K 5% 1/4W
R5420 1-249-421-11 CARBON 2.2K 5% 1/4W
R5421 1-249-385-11 CARBON 2.2 5% 1/4W
R5422 1-249-405-11 CARBON 100 5% 1/4W
R5423 1-215-915-11 METAL OXIDE 470 5% 3W
R5424 1-249-395-11 CARBON 15 5% 1/4W
R5425 1-216-017-91 RES-CHIP 47 5% 1/10W
R5427 1-249-395-11 CARBON 15 5% 1/4W
***************************************************************
ACCESSORIES AND PACKING MATERIALS
***************************************
1-569-008-21 ADAPTOR, CONVERSION 2P (KV-DR29M89)
3-701-910-00 SCREW, SPECIAL (DIA. 3.8X20)
* 4-029-168-01 BAG, PROTECTION (KV-DR29M39/M69/M89)
* 4-054-764-01 BAG,PROTECTION (KV-DR29M63)
4-065-210-01 JOINT
* 4-086-732-02 INDIVIDUAL CARTON
(KV-DR29M39/M69/M89)
* 4-088-350-01 INDIVIDUAL CARTON (KV-DR29M63)
* 4-087-147-01 CUSHION, UPPER (KV-DR29M39/M69/M89)
* 4-088-352-01 CUSHION, UPPER (KV-DR29M63)
* 4-087-148-01 CUSHION, LOWER (KV-DR29M39/M69/M89)
* 4-088-353-01 CUSHION, LOWER (KV-DR29M63)
4-088-297-11 MANUAL, INSTRUCTION(KV-DR29M39)
4-088-356-11 MANUAL, INSTRUCTION (KV-DR29M63)
4-088-512-11 MANUAL, INSTRUCTION (KV-DR29M69)
4-088-298-11 MANUAL, INSTRUCTION (KV-DR29M89)
* 4-086-733-01 TRAY (KV-DR29M39/M69/M89)
* 4-088-351-01 TRAY (KV-DR29M63)
4-392-003-11 BAND, HOLD (KV-DR29M39/M69/M89)
4-392-003-21 BAND, HOLDING (KV-DR29M63)
4-392-004-11 CLIP (KV-DR29M39/M69/M89)
4-059-705-01 CLIP (KV-DR29M63)
***************************************************************
BATTERY COVER REMOTE COMMANDER
***************************************
1-477-313-11 REMOTE COMMANDER (RM-991)
4-079-833-01 BATTERY COVER REMOTE COMMANDER
