Sony TRINITRON KV-DR29M39 - Page 44

– 44 –
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
3DNR
4M BIT SDRAM
IC801
V
H
V
IC602
IC802
(TC90A90F)
NT PLL
27M
Y2
LPF
IC601
DRC 1 CHIP
(CXD2095AQ)
DRC PROCESS
525i
525i
625i
625i
525p
1050i
625p
1250i
PLL
TLC2932I
PLL
TLC2933
IIC BUS EXPANDER
(CXA1875)
LEVEL
CONVERTER
LEVEL
CONVERTER
Q902, Q908, FL902
BUFFER & FILTER
Q903, Q909, FL903
BUFFER & FILTER
Q901, Q907, FL901
BUFFER & FILTER
16M BIT SDRAM
2.5V 3.3V
H OUT
Y
Cr-Y
Cb-Y
IC506
CN502
IC505
IC604
Y
8
8
Cr-Y/Cb-Y
13.5MHz
Y
Cr-Y
Cb-Y
CKIN
27MHz
HREF
HREF
RPLLHD
54MHz
CLOCK
5.0V
IC603
IC504
Y
Cr-Y
Cb-Y
(DIGITAL REALITY CREATION-MF, 3D NOISE REDUCTION)
B3
VP 100 OUT
9
8
37
31
35
33
39
10
14
12
HP 100 OUT
V-PULSE IN
Y-MAIN IN
V-MAIN IN
U-MAIN IN
H-PULSE IN
Y OUT
V OUT
U OUT
