Sony TRINITRON KV-DR29M39 - Page 70

– 84 –
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
P BOARD VOLTAGE LIST AND WAVEFORM (EXCEPT KV-DR29M63)
V2 BOARD VOLTAGE LIST AND WAVEFORM (EXCEPT KV-DR29M63)
Ref Pin No. Voltage[v]
IC8801 1 1.4
2 (1.7)[1.4]
3 0.2
4 0.1
5 4.4
6 4.4
7 3.3
80
90
10 0.8
11 0
12 0
13 0
14 0
15 0
16 0.7
17 0.3
18 0.7
19 3.3
20 0
21 3.3
22 3.3
23 0
24 1.7
25 1.2
26 1.7
27 2.1
28 2.0
IC8802 I 4.9
G0
O 3.3
Q8801 B 0.7
C0
E 1.4
Ref Pin No. Voltage[v]
Q8802 B 0.9
C0
E 1.6
Q8803 B 0.7
C0
E 1.4
Q8804 B 4.7
C0
E 4.9
Q8805 B 1.9
C0
E 2.6
Q8806 B 0.3
C 3.3
E 0.3
Q8807 B 0.1
C 3.3
E 0.1
Q8808 B 2.5
C0
E (1.6)[3.2]
Q8809 B 2.6
C0
E 3.3
Q8810 B 2.5
C0
E 3.2
Q8811 B 0.3
C0
E 0.9
Q8812 B -0.5
C 2.6
E0
Ref Pin No. Voltage[v]
IC5801 1 0
20
30
40
50
60
70
80
90
10 0
11 0
12 0
13 0
14 0
15 0
16 0
17 0
18 0
19 0
20 0
21 0
22 0
23 2.2
24 0
25 2
26 2.4
27 0
28 0
29 0
30 0
31 2.5
32 0
Ref Pin No. Voltage[v]
33 0
34 0
35 0
36 1.3
37 0
38 0
39 3.3
40 0
41 2.4
42 2.4
43 0
44 0
45 0
46 0
47 0
48 0
49 0
50 4.6
51 0
52 0
Q5801 B 0
C5
E0
Q5803 B 0.6
C0
E0
Q5805 B 0.5
C 1.3
E0
Q5810 B 0.4
C 3.6
E0
