Sony TRINITRON KV-DR29M39 - Page 71

– 85 –
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
Ref Pin No. Voltage[v]
IC9001 1 3.5
212
3 3.4
40
5 9.0
6 200
7 152
8 (158)[154]
9 (152)[148]
IC9002 1 3.5
212
3 3.4
40
5 8.9
6 200
7 157
8 170
9 156
IC9003 1 3.5
212
3 3.3
40
5 9.0
6 200
7 154
8 160
9 153
J9001 G2 (565)[560]
H1 0
23.6Vp-p
4
H2 0
Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]
C BOARD VOLTAGE LIST AND WAVEFORM
KB 160
108Vp-p
NTSC3.58
3
116Vp-p
PA L
3
KG (168)[170]
86Vp-p
NTSC3.58
2
96Vp-p
PA L
2
KR (158)[154]
120Vp-p
NTSC3.58
1
108Vp-p
PA L
1
Q9001 B 8.4
C0
E 4.6
Q9003 B 0
C12
E 2.9
Q9004 B 0
C12
E 2.8
Q9005 B 0
C12
E 2.8
Q9009 B 2.9
C0
E 3.5
Q9010 B 2.8
C0
E 3.4
Q9011 B 2.8
C0
E 3.4
3.2Vp-p
5
2.5Vp-p
6
4.3Vp-p
7
