1-12
PVM-14L2/20L2
1-4-5. G Board Removal (20 inch)
* Remove the G and Q block assy beforehand.
1-4-4. G and Q Block Assy Removal (20 inch)
CN509
CN607
CN1506
CN1502
CN605
CN3502
CN510
CN603
CN2707
CN2710
CN2705
CN602
4
Focus lead assy
7
Earth plate
5
Screw
(+PS 4
x
8)
6
Screw
(+PS 4
x
8)
3
Screw
(+PS 4
x
8)
A
B
2
Anode cap
8
Remove the G, Q block assy
in the direction of the arrow B.
1
Remove the lead holder
in the direction of the arrow A.
Three claws
4
G board
3
Q block assy,
Main plate assy
1
Screw
(+BVTP3 x 12)
2
PC board holder
To Next Page
