Sony VPL-CS7 - Fan (Sirocco;For Lamp)

1-11
VPL-CS7/ES2
C board
1 Two screws
(+BTP3 x10)
2 Fan bracket
5 Remove the D.C. fan (Sirocco/For lamp)
in the direction of the arrow.
3 Two dowels
6 D.C. fan (Sirocco/For lamp)
Fan holder
4 Loosen the screw.
1-3-15. D.C. Fan (Sirocco/For Lamp)
. Remove the side panel assembly-1,2. (Refer to 1-3-11, 12)
. Remove the G board. (Refer to 1-3-13.)
