Sony ZS-2000 - Page 34

MIAN BOARD
LINE BOARD
1-677-452-
11
(11)
11
(11)
11
(11)
04
1-677-455- 1-677-455-
SP301
L-CH
SPEAKER
SP302
R-CH
SPEAKER
1-676-084-
4
CONTROL BOARD
CN801
10
CD BOARD
CN704
14
TU BOARD
1
TU
BOARD
CNP1
7
6
POWER BOARD
CN903
POWER BOARD
CN902
13
CD BOARD
CN701
3
FL BOARD
CN502
8
REG
BOARD
CN310
SPK (R)
BOARD
SPK (L)
BOARD
CNP305
IC401
OPTICAL
DIGITAL
OUT(D)
J402
LINE IN
1
A
B
C
D
E
F
G
H
I
J
23456789101112131415
11
(11)
ZS-2000
– 43 – – 44 –
6-12. PRINTED WIRING BOARDS — MAIN SECTION —• Refer to page 24 for Circuit Boards Location.
• Refer to page 31 for Note.
Q300 D-9
Q301 F-10
Q302 E-9
Q303 F-8
Q304 F-9
Q305 H-5
Q306 G-11
Q307 E-9
Q308 E-8
Q309 G-13
Q310 G-13
Q311 G-12
Q312 H-12
Q313 G-13
Q353 E-6
Q357 C-7
Q358 D-7
Q359 D-7
Q361 E-7
Q362 D-5
D301 E-7
D302 E-7
D303 G-11
D304 G-11
D305 H-6
D306 H-6
D350 E-6
D351 D-6
D354 E-9
D355 E-13
IC301 D-11
IC303 F-9
IC304 C-8
IC305 C-7
IC401 G-2
Q105 G-6
Q106 E-11
Q205 G-6
Q206 E-12
• Semiconductor Location
Ref. No. Location Ref. No. Location
(Page 47)
(Page 52)
(Page 55)
(Page 55)
(Page 36)
(Page 35)
(Page 32)
(Page 55)
(Page 32)
