– 71 –
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3323-474-A CD BOARD, COMPLETE
*******************
< CAPACITOR >
C700 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C701 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C702 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C703 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C704 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
C705 1-131-375-00 TANTALUM 4.7uF 10% 10V
C706 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C707 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C708 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C709 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
C710 1-126-961-11 ELECT 2.2uF 20% 50V
C711 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C712 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C713 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C714 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C715 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C716 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C717 1-126-965-11 ELECT 22uF 20% 50V
C718 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C719 1-104-664-11 ELECT 47uF 20% 10V
C720 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C721 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C722 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C723 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C724 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C725 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C726 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C727 1-126-934-11 ELECT 220uF 20% 16V
C728 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C729 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C730 1-126-925-11 ELECT 470uF 20% 10V
C731 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C732 1-104-665-11 ELECT 100uF 20% 10V
C733 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C740 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C741 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C742 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C743 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C744 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C745 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C746 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C747 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C748 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C749 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C750 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C751 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C752 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C753 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C754 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C755 1-126-924-11 ELECT 330uF 20% 10V
C756 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C757 1-104-664-11 ELECT 47uF 20% 10V
C758 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C759 1-104-664-11 ELECT 47uF 20% 10V
C760 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C761 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C762 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C763 1-124-473-11 ELECT 1000uF 20% 10V
C764 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C765 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C766 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C770 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C773 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C774 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C775 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C776 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C777 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C780 1-126-963-11 ELECT 4.7uF 20% 50V
C781 1-126-963-11 ELECT 4.7uF 20% 50V
C788 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN711 1-770-528-31 CONNECTOR, FFC/FPC 21P
CN712 1-695-374-31 CONNECTOR, FFC/FPC 13P
* CN713 1-580-166-11 PIN, CONNECTOR (PC BOARD) 5P
< IC >
IC701 8-752-082-14 IC CXA1992BR
IC702 8-752-384-13 IC CXD2589Q
IC703 8-759-473-42 IC BA6898FP
< COIL >
L701 1-410-993-42 INDUCTOR CHIP 1uH
L702 1-410-997-42 INDUCTOR CHIP 2.2uH
L703 1-410-997-42 INDUCTOR CHIP 2.2uH
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
CD
