Sony ZS-2000 - Page 36

ZS-2000
– 47 – – 48 –
IC801 G-8
IC802 G-11
IC803 F-10
IC804 G-5
Q801 G-10
Q802 G-10
Q803 G-6
Q804 E-8
Q805 G-12
Q806 G-13
• Semiconductor
Location
Ref. No. Location
6-14. PRINTED WIRING BOARDS — CONTROL SECTION —• Refer to page 64 for Circuit Boards Location.
• Refer to page 31 for Note.
(Page 43)
(Page 52)
(Page 36)
SWITCH(1) BOARD
SWITCH(2) BOARD CONTROL BOARD VOLUME BOARD
5
1-676-857-
1-676-856-
(11)
11
1-676-089-
1-676-087-
04
CD BOARD
CN712
2
FL BOARD
CN501
4
MAIN BOARD
CN301
OPERATE
SNOOZE
MEGA BASSBASS/TREBLE
VOLUME
TIME SIGNAL
SLEEP
CLOCK TIMER STANDBY
PRESET
SUMMER
TIME
RADIO/BAND
AUTO PRESET
CLOCK
AUTO ADJUST
PLAY MODE
MONO/ST
DISPLAY
ENTER MEM
TUNE
TIME SET
CD
OPEN/CLOSE
LINE
RDS
> + B X x . -
1
A
B
C
D
E
F
G
H
I
2 3 4 5 6 7 8 9 1011121314
SG
(TEST-A)
(11)
11
(11)
11
(11)
11
