PWM / 0-10V max.
With this value, the maximum voltage level / maximum frequency can be specified for the highest speed of the energy saving pump,
which is used, for example, during the flushing or manual operation.
Speed when „On“
In this menu, the calculation basis of the displayed speed is changed. If, for example, 30% is specified here, the frequency/voltage set
under “PWM On” / “0-10V On” will be displayed during creation so that a 30% speed is present. When creating the voltage/frequency
of PWM Max / 0-10V Max, 100% speed is displayed. Temporary values are calculated correspondingly.
This function does not influence the rule, but rather only the display on the status screen.
Example for pump settings
Technical data PWM and 0-10V
Show signal
Represents the set pump signal in a graphic and text overview.
61
