iv
SAFETY SYMBOLS
CAUTION
Risk of Electrical Shock
CAUTION
Refer to Accompanying Documents
Off (Supply)
Standby (Supply)
On (Supply)
Direct Current (DC)
Alternating
Three–Phase
Fuse
Earth (Ground) Terminal
Protective Conductor Terminal
Current (AC)
ABOUT THIS MANUAL
This manual has been written expressly for the Sorensen DCS 1KW series of power supplies
which have been designed and certified to meet the 1997 Low Voltage and Electromagnetic
Compatibility Directive Requirements of the European Community. Units that comply with the
directive are designated by an ‘E’ after the model designator (e.g., DCS 40-25E would indicate
that the model is certified) when configured for 230 VAC input only.
Since the goal of the Low Voltage Directive is to ensure the safety of the equipment operator,
universal graphic symbols (see below) have been used both on the unit itself and in this manual
to warn the operator of potentially hazardous situations.
