FEATURES and SPECIFICATIONS SORENSEN DCS SERIES MANUAL
1-2
• External indicator signals for remote monitoring of OVP status, local/remote programming status,
thermal shutdown, and output voltage and current.
• Optional IEEE-488 interface for complete remote programming and readback capability.
1.4 Specifications
1.4.1 Electrical Specifications
1
MODELS 8-125 20-50 33-33 40-25 50-20 60-18 80-13 150-7 300-3.5 600-1.7
Output Ratings:
Output Voltage
Output Current
Output Power
0-8V
0-125A
1000W
0-20V
0-50A
1000W
0-33V
0-33A
1089W
0-40V
0-25A
1000W
0-50V
0-20A
1000W
0-60V
0-18A
1080W
0-80V
0-13A
1040W
0-150V
0-7A
1050W
0-300V
0-3.5A
1050W
0-600V
0-1.7A
1020W
Line Regulation
2
:
Voltage
Current
8 mV
125 mA
20 mV
50 mA
33 mV
33 mA
40 mV
25 mA
50 mV
20 mA
60 mV
18 mA
80 mV
13 mA
150 mV
7 mA
300 mV
3.5 mA
600 mV
1.7 mA
Load Regulation
3
:
Voltage
Current
8 mV
125 mA
20 mV
50 mA
33 mV
33 mA
40 mV
25 mA
50 mV
20 mA
6 0mV
18 mA
80 mV
13 mA
150 mV
7 mA
300 mV
3.5 mA
60 0mV
1.7 mA
Meter Accuracy:
Voltage
Current
0.09V
1.35A
0.3V
0.6A
0.43V
0.43A
0.5V
0.35A
0.6V
0.30A
0.7V
0.28A
0.9V
0.23A
1.6V
0.08A
4.0V
0.045A
7.0V
0.018A
OVP Adjustment Range 0.4-8.8V 1.0-22V 1.65-36.3V 2-44V 2.5-55V 3-66V 4-88V 7.5-165V 15-330V 30-660V
Output Noise and Ripple (V)
rms
p-p
(20Hz-20MHz)
10 mV
100 mV
4
10 mV
100 mV
4
10 mV
100 mV
4
10 mV
100 mV
4
20 mV
100 mV
20 mV
100 mV
20 mV
100 mV
30 mV
200 mV
40 mV
200 mV
100 mV
500 mV
1
Specifications are warranted over a temperature range of 0-50°C with default local sensing. From 50-70°C, derate output 2% per °C.
2
For input voltage variation over the AC input voltage range, with constant rated load
3
For 0-100% load variation, with constant nominal line voltage
4
Typical P-P noise and ripple is 50 mV
AC Input: 200-250 Vac at 10 A rms or 100-130 Vac at 20 A rms, 47-63 Hz
Maximum Voltage Differential from output to safety ground: 600 Vdc
Additional Characteristics
MODELS 8-125 20-50 33-33 40-25 50-20 60-18 80-13 150-7 300-3.5 600-1.7
Stability
1
:
Voltage
Current
4 mV
62.5 mA
10 mV
25 mA
16.5 mV
16.5 mA
20 mV
12.5 mA
25 mV
10 mV
30 mV
9 mA
40 mV
6.5 mA
75 mV
3.5 mA
150 mV
1.75 mA
300 mV
0.85 mA
Temperature Coefficient
2
:
Voltage
Current
1.6 mV
37.5 mA
4 mV
15 mA
6.6 mV
9.9 mA
8 mV
7.5 mA
10 mV
6 mA
12 mV
5.4 mA
16 mV
3.9 mA
30 mV
2.1 mA
60 mV
1.05 mA
120 mV
0.51 mA
Maximum Remote Sense
Line Drop Compensation
/line
0.5V 1V 1V 1V IV 1V 1V 1V 1V 1V
1
Maximum drift over 8 hours with constant line, load, and temperature, after 20 minute warm-up
2
Change in output per °C change in ambient temperature, with constant line and load
