SORENSEN DCS SERIES MANUAL FEATURES and SPECIFICATIONS
1-3
Altitude: 2000M (6562 Ft.)
Storage Temperature Range: -55 to +85°C
Humidity Range: 0 to 80% Non-condensing
Time Delay from power on until output stable: 3 seconds maximum
Voltage Mode Transient Response Time: 1mS recovery to 1% band for 30% step load change from 70% to 100% or
100% to 70%
Remote Start/Stop and Interlock: TTL compatible input, Contact Closure, 12-250 Vac or 12-130 Vdc
Switching Frequency: Nominal 70 kHz (140 kHz output ripple)
Analog Programming Linearity: Typical error is less than 0.5% setting. Maximum error is 1% of rated output.
Agency Approvals: CE Pollution Degree 2 (UL pending)
Remote Analog Programming (Full Scale Input)
Scales are selectable via an internally-mounted switch.
PARAMETER RESISTANCE VOLTAGE CURRENT
Voltage
5 kΩ
5V, 10V 1 mA
Current
5 kΩ
100 mV, 5V, 10V 1 mA
OVP
5 kΩ
5V, 10V 1 mA
1.4.2 Mechanical Specifications
HEIGHT WIDTH DEPTH WEIGHT
Single Unit
44 mm 482.6 mm 508 mm 8.2 kg
(1.75 in) (19 in) (20 in) (18 lbs)
Output Connector
•• Models DCS 8-125 through DCS 80-13
Connector type: Nickel plated copper bus bars.
Approximate dimensions: 1.365" x 0.8" x 0.125"
Distance between positive and negative bus bar centers: 2.2"
Load wiring mounting holes: Two 0.257" diameter holes on 0.5" centers (1/4" hardware)
Two 0.191" diameter holes on 0.4" centers (#10 hardware)
•• Models DCS 150-7 through DCS 600-1.7
Connector type: Six pin Amp Universal Mate-N-Lok connector
Chassis mounted parts: Housing: Amp part number 1-480705-0
Pins: Amp part number 350547-1
Mating connector parts: Housing: Amp part number 1-480704-0
Socket pins: Amp part number 350550-1
Note: Eight Socket pins and one mating connector housing are supplied with each 150V through 600V unit.
Input Connector
2 position terminal block plus safety ground screw.
Note: Input power cord not supplied.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
