PARTS LISTS SORENSEN DCS SERIES MANUAL
5-2
Table 5-2. DCS 1 kW Parts Lists
Number Assembly
1066830-008 Output PCB Assembly
1066830-01 Output PCB Assembly
1066830-020 Output PCB Assembly
1066830-080 Output PCB Assembly
5360726-01 Rectifier PCB Assembly
5360726-02 Rectifier PCB Assembly
5360726-03 Rectifier PCB Assembly
5360726-04 Rectifier PCB Assembly
5360800-01 Final Assembly
5360800-02 Final Assembly
5360800-03 Final Assembly
5360800-04 Final Assembly
5360800-05 Final Assembly
5360800-06 Final Assembly
5360800-07 Final Assembly
5360800-08 Final Assembly
5360800-09 Final Assembly
5360800-10 Final Assembly
5360801-01 Front Panel PCB Assembly
5360801-02 Front Panel PCB Assembly
5360802-01 Mother PCB Assembly
5360802-02 Mother PCB Assembly
Table 5-3. DCS 1 kW Parts Lists By Model Number
Final
Assembly
Mother PCB
Assembly
Front Panel
PCB Assembly
Output PCB
Assembly
Rectifier PCB
Assembly
Model
DCS8-125E
5360800-01 5360802-01 5360801-01 1066830-008 N/A
Model
DCS20-50E
5360800-02 5360802-01 5360801-02 1066830-020 N/A
Model
DCS33-33E
5360800-03 5360802-01 5360801-02 1066830-01 5360726-01
Model
DCS40-25E
5360800-04 5360802-01 5360801-02 1066830-01 5360726-02
Model
DCS50-20E
5360800-10 5360802-01 5360801-02 1066830-01 5360726-02
Model
DCS60-18E
5360800-05 5360802-01 5360801-02 1066830-01 5360726-03
Model
DCS80-13E
5360800-06 5360802-01 5360801-02 1066830-080 5360726-04
Model
DCS150-7E
5360800-07 5360802-02 5360801-01 N/A N/A
Model
DCS300-3.5E
5360800-08 5360802-02 5360801-01 N/A N/A
Model
DCS600-1.7E
5360800-09 5360802-02 5360801-01 N/A N/A
