Motherboard Description
SY-7VBA133U
7
A ATX Power Supply
B CPU Cooling Fan Connector
C Connector Socket 370 Connector
D VIA 6946T North Bridge chip
E DIMM Banks
F Bus Mastering E-IDE/ATAPI Ports
G 32-bit AGP Slot
H 32-bit PCI Mastering Slots
I CMOS Clear Jumper
J Chassis Cooling Fan Connector
K Floppy Disk Drive (FDD) Port
L USB Ports
M Front panel connectors
N VIA 686B South Bridge Chip
O 3V Lithium Battery
P 16-bit ISA Slot
Q Serial Infrared (IrDA) Device Header
R Flash BIOS
S Wake-On-LAN (WOL) Header
T CD-IN Connector
U Onboard Audio Chip
V Back panel Connectors
