BIOS Setup Utility
SY-7VBA133U
67
The following tables describe each field in the INTEGRATED
PERIPHERALS Menu and provide instructions on how to configure the
IDE controls, FDC controls, and the onboard serial and parallel ports.
3-5.1 IDE Device Controls
IDE Controls Setting Description Note
Disabled Turn off the on-board
IDE
On-Chip PCI IDE
Primary
Secondary
Enabled Use the on-board IDE Default
mode 0-4 0 is the slowest speed
4 is the fastest speed
IDE
Primary Master PIO
Primary Slave PIO
Secondary Master PIO
Secondary Slave PIO
Auto For better performance
and stability, we suggest
you use the Auto setting
to set the HDD control
timing.
Default
Disabled
IDE
Primary Master UDMA
Primary Slave UDMA
Secondary Master UDMA
Secondary Slave UDMA
Auto Select Auto to enable
Ultra DMA Mode
support.
Default
3-5.2 Keyboard Controls
Keyboard Controls Setting Description Note
PCI Slot
Init Display First
AGP
Choose which card – AGP
Display card or PCI VGA card –
to initialize first.
Default
3-5.3 IDE HDD Block Mode
Setting Description Note
Disabled
IDE HDD Block Mode
Enabled Invokes multi-sector
transfer instead of one
sector per transfer. Not
all HDDs support this
function.
Default
