Section1 To the installer
ELECTRICAL:
Voltage AC: 1 Phase 200-240V 50 Hertz
Total Run Amps: 12 Amps
Drive Motors: 1.5 HP
Main Compressor: 3150 BTU/Hr.
(BTU may vary depending on compressor used.)
COOLING
Air-cooled required minimum 15.2cm air clearance around the freezer.
HOPPER
Two hoppers, 8 liters×2, refrigerated and insulated.
MACHINE VIEW
1. Top cover
2. Spigot switch cover
3. Dispensing door nut
4. Dispensing door
5. Drip pan
6. Leg-Plastic
7. Rear seal drip
8. Control Panel
9. Panel attaching lock
