Page 21
Section6 Operating Procedures
Disassembly
Step 1
BE SURE THE POWER KEYPAD IS IN THE “OFF” POSITION.
Step 2
Remove the hand screws and the dispensing door. Remove the beater assembly from
the freezing cylinders and take these parts to the sink for cleaning.
Step 3
Remove the front drip tray and the splash shield from the freezer. Take them to the sink
for cleaning.
Brush cleaning
Step 1
Prepare a sink with an approved cleaning solution. USE WARM WATER AND FOLLOW
THE MANUFACTURER’S SPECIFICATIONS.
IMPORTANT: Follow label directions, as too STRONG of a solution can cause parts
damage, while too MILD of a solution will not provide adequate cleaning. Make sure all
brushes are available for brush cleaning.
Step 2
Remove the O-rings from the drive shaft of the beater assembly.
Note: To remove the O-ring, use a single service towel to grasp the O-ring. Apply
pressure in an upward direction until the O-ring pops out of its groove. With the other
hand, push the top of the O-ring forward, and it will roll out of the groove and can be
easily removed. If there is more than one O-ring to be removed, always remove the rear
O-ring first. This will allow the O-ring to slide over the forward rings without falling into
the open grooves.
Step 3
From the freezer door, remove the design cap, draw valve handle, valve lifter arm, and
draw valve. Remove all O-rings.
Step 4
Remove the large O-rings and front bearing from the back of the freezer door.
Step 5
Return to the freezer with a small amount of cleaning solution. With the black bristle
brush, brush clean the rear shell bearing at the back of the freezing cylinder.
