Page6
Section4 Installation Instructions
G. Install the standpipe into the hopper (Figure 4-5, 4-6).
H. Connect the power cord. Check the nameplate on the freezer for supply. The unit
must be connected to a properly grounded receptacle.
I. When connect the power supply and press on the ON/OFF switch, the fluorescent
display indicate:
J. Press STOP button, then press P button indicate temperature of cylinder and hopper.
IMPORTANT: If one or both of two temperature value(s) indicate(s) “00C”, you must STOP machine
and contact the authorized service technician to check the temperature sensor connection.
Caution
This Equipment Must Be Properly Grounded! Failure To Do So Can Result In
Severe Personal Injury From Electrical Shock!
PANEL REMOVAL:
To remove the panel, using a
flat head screwdriver into the
panel attaching lock.
Turn the lock in the direction
shown in Figure 4-7.
HOPPER TEM. 10C
CYCLINDER TEM. 10C
