a. Place O-rings on side draw valves; place H-ring on
middle draw valve; place O-rings on prime plugs;
coat all ring areas with Spaceman lubricant.
b. Push prime plugs into holes on top of dispensing
door.
c. Insert draw valves into dispensing door; middle
draw valve goes in the middle and slots face
outward.
d. Set draw handles into slots on dispensing door,
with adjustment screws facing down.
e. Slide retenon pin through draw handles; secure
with nut.
f. Snap design caps onto boom of dispensing door.
g. Fit gaskets into grooves on back of door, at side
out; slide beater guides over beater rods, with
anged edges against the door.
h. Insert dispensing door assembly into cylinders,
beater rods rst, pushing handles all the way up as
you insert.
i. Secure door assembly in a cross-paern using
hand-screws, with the long hand-screws on top.
a. Place O-rings on rear shells, coang with
Spaceman lubricant; install gears into shells (they
only t one direcon).
b. Connect covers and shells, ensuring they t ush;
secure with hand-screws.
c. Place O-rings on sucon tubes; lightly lubricate
O-ring areas.
d. Place air pump stoppers into air pump springs,
verifying orientaon of stopper in spring; insert
into housings stopper-rst.
e. Insert sucon tubes into pumps; rotate to lock,
and turn to desired overrun seng.
f. Coat air pump drive shas with Spaceman
lubricant.
g. Install air pumps onto machine:
→ insert at an angle
→ while pushing air pump in, slightly rotate back
and forth unl the gear engages the air pump
drive sha
→ push in and rotate counter-clockwise to lock in
place
h. Assemble air tubes; each air tube has O-rings,
connectors, and check valve; lubricate O-ring
areas.
i. If machine will go unused, install air tubes into
hopper, but do not connect to air pumps;
otherwise, set air tubes aside unl aer machine
has been primed.
