Spearhead Multicut 300 - Splitter Gearbox Details; Rotor Gearbox Details

8999151EN: v1 11/03/2021
64
Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
Splitter Gearbox
Figure 5.2 – Multicut Splitter Gearbox
(Guard requires removal)
No.
Description.
1
Fill Plug
2
Drain Plug
3
Level Plug
Table 5.2 – Multicut Splitter Gearbox Components
Rotor Gearboxes
Figure 5.3 – Multicut Rotor Gearboxes
(Guard requires removal)
No.
Description.
1
Dipstick
2
Drain Plug
3
Upper Fill Mark
4
Lower Fill Mark
Table 5.3 – Multicut Rotor Gearbox Components
