5.2.4 Greasing Schedule
Equipment Required
• Manually operated grease gun supplying NLGI #2 Molybdenum Disulphide Grease to M6/M8
grease nipples
With reference to the position of grease points in Figure 5.7, the following greasing schedule should be adhered
to, to ensure reliability and longevity in components.
IMPORTANT: With extended and harder working conditions, these greasing times may need to be shortened to
compensate for the machine more intensive work requirements.
NOTE: All values throughout this section are given on the assumption that a manually operated grease gun is
used to carry out the greasing procedures giving a predicted quantity of 0.8-1.0g of grease per pump.
WARNING! It is mandatory to switch the combustion engine off and disengage PTO and ensure that
the tractor and machine is stopped, the ignition key is removed from the dashboard and the parking
brake is engaged before leaving the driver’s seat and proceeding to carry out maintenance on any of the
PTO shafts.
Grease Point
Qty (pumps)
Frequency
Input PTO Shaft
See Section 5.2.2 - Input Shaft (1)
Connecting Shaft
See Section 5.2.2 – Connecting Shaft (2)
Drawbar
2
Every 8 hours
Wheel Arm
2
Every 8 hours
Wheel Hubs
2
Every 8 hours
Table 5.7
Greasing Schedule For Various Components
5.3 PTO Shaft
Spearhead Multicut machines feature Bondioli & Pavesi input PTO shafts. PTO shafts require routine
maintenance and sometimes more demanding maintenance requirements to ensure their longevity and reliability
of service.
For frequent greasing requirements of the various driveline shafts on the machine; see Section 5.2.2.
5.3.1 Size Adjustment & Fitting To The Tractor
The input PTO shaft supplied with the Multicut machine will be of standard supply as it came from the original
manufacturer.
The input PTO shaft will be required to be modified/adjusted in order to fit the desired operating tractor. For
guidance in how to carry this out; see Section 3.3.3.
For fitting the input PTO shaft between the machine and the tractor; see Section 4.4.
5.3.2 Greasing
For the greasing requirements on all Multicut input and connecting shafts, refer to Section 5.2.2.
