2.5 Safety & Operational Decals
Multicut machines are equipped with safety and operational decals warning about residual risks present on the
machines that were not possible to eliminate. Some give guidance in how to best operate and care for the
machine. Safety decals are yellow in colour and placed in strategic positions around each of the respective
dangers. Operational decals are generally white in colour and are placed in locations close to the respective item
required to be maintained. Section 2.5.1 specifies the meaning of each of the symbols contained in the decals
and their particular positioning on the machine is stated in Section 2.5.2. The operator must memorise the
meaning of these decals.
All decals should be kept clean and replaced immediately if they are fully/partially detached or damaged by
purchasing them through a local Spearhead dealer.
2.5.1 Definitions
1
A
B
C
D
E
F
G
H
I
J
Figure 2.1 – 8770617 Safety Decal
a
Warning: - Remove key, read
instruction manual
The original machine operators manual should be read before using
the machine giving guidance to operation and maintenance
b
Instruction: - Check the
tightness of fasteners
The tightness of all fasteners around the machine should be checked
at least once every 8 hours
c
Danger: - Do not stand ride on
the machine
The machine should be at no point be ridden on; whether in transport
or during work
d
Danger: - Cutting hazard from
rotating blades
Personnel should keep at distance from the machine when the
machine is operating
e
Danger: - Flying debris
Personnel should keep at distance from the machine when the
machine is operating due to the risk of items being flung from the
machine
f
Danger: - Crushing hazard if
unsupported
Personnel should keep at distance from the machine when the
machine is unsupported as of the risk of the wing and other items
falling posing potential entrapment or crushing
g
Danger: - Operating area
hazard
Personnel should keep at distance from the machine when the in
operation as of the risk of entanglement or crushing by components
h
Danger: - Wear ear protection
Personnel should wear hearing protection when in close proximity to
the machine in operation to prevent permanent hearing damage
i
Warning/Instruction: - Explosion
hazard
Check the working site before proceeding to use the machine.
j
Warning/Instruction: - Clear
deck of debris
It is important to ensure that the machine decks are clear of debris to
stop the risk of fire. Never drive over fire with the tractor and machine.
Table 2.1 – 8770617 Safety Decal Definitions
