Alignment
Note that the analyzer was adjusted to the mounting flange axis during specification.
4.5 Vacuum Installation
1. Open the transport box carefully.
2. Check the shock and tilt sensors. If any sensor is discolored, please inform SPECS
immediately and await further instructions.
3. Remove the shipping frame.
4. Carefully lift the analyzer out of the box. Be aware of outstanding parts while
pulling out the analyzer. In particular the rotary feedthroughs are sensitive to
physical jostling / bumping / vibrations. Because of the analyzer weight of ~ 65
(PHOIBOS100) / 95 kg (PHOIBOS150).
PHOIBOS 41
