20
THROTTLE & BRAKE/REVERSE
THROTTLE CURVE-
Throttle response is adjustable using an EXPO or Custom throttle curves.
The Throttle & Reverse screen allows for programming of all throttle and brake
functions.
AVAILABLE FUNCTIONS:
• Throttle Curve
• Throttle Trim
• Throttle Rate
• Reverse Rate
• Traction Control
• ABS
• Servo Speed
• Channel Properties
• Travel
• Subtrim
• Reverse
Standard- Linear throttle output (default)
Exponential- Positive (+) EXPO values decrease
throttle sensitivity around neutral.
Custom- Up to 7 selected points can be adjusted
to custom tailor throttle response throughout the
range.
• Tap on the line to add points.
• Tap on a point to adjust its position using the
sliders below.
• Delete a point by tapping on it, then select
Delete point (red box above graph)
On-the-Fly Button- Select a switch for instant
adjustment of the expo curve while driving.
