PHYSICAL TRANSMITTER ADJUSTMENTS
The DX6R is designed to be extremely adjustable to suite a wide variety of driver
needs. All control inputs can be configured for Left or Right handed driving and
can be adjusted for angle and spring tension.
AVAILABLE ADJUSTMENTS:
• Adjustable trigger and steering tension
• Multiple trigger position
• Multiple wheel drop-down options
• 10˚ and 15˚ Steering Adapters
• Small and Large Steering Wheel
• Left- or right-hand steering
• 3 grip sizes
THROTTLE DISTANCE/
ANGLE
• 2.5mm hex wrench
• loosen 1 to 2 turns.
• Adjust IN or OUT.
• Tighten
THROTTLE TENSION
• 1.5mm hex wrench
• Clockwise to decrease
tension
STEERING TENSION
• 1.5mm hex wrench
• Clockwise to increase
tension
