Spectrum DX6R - Auxiliary Channel Setup

24
AUXILIARY (AUX) CHANNEL SETUP
AUX CURVE-
AUX channel response is adjustable using an EXPO or Custom curves.
INPUT CONTROL-
• Select button or switch for control
• Select how many positions
• Select how many steps for each button press
The AUX setup screen allows for programming of all auxiliary channel functions.
AVAILABLE FUNCTIONS:
• Input Control
• AUX Curve
• AUX Speed
• Channel Properties
• Travel
• Subtrim
• Reverse
Standard- Linear output (default)
Exponential- Positive (+) EXPO values decrease
sensitivity around neutral.
Custom- Up to 7 selected points can be adjusted
to custom tailor AUX channel response throughout
the range.
• Tap on the line to add points.
• Tap on a point to adjust its position using the
sliders below.
• Delete a point by tapping on it, then select
Delete point (red box above graph)
