Document No: 9961 Revision: F Issue Date: Jan-29-2018 Page 13 of 35
This document and all copies are the property of Spider
®
. All dimensions and data are indicative only.
The user must ensure that the equipment complies with local rules and regulations.
®
continued
Feature Function
Voltage Indicator Light Easy visual inspection can eliminate a
service call
Remote Ready Built-in pendant port accepts plug-
in remote control
Compatible with 8-0281 series and
709854-xx series (units built after
3/2014) remotes
No need to drill and wire remote into
hoist
Leaves hoist mounted controls operable
®
Feature Function
Optional Top Limit Switch Stops upward travel on contact
with an overhead obstruction
Easy installation
Optional* Overload Kit
*standard feature on Canadian hoists
Allows overload to be shop-set
to 750 lbs (1,250 lbs on 1,500-lb
models)
Reduces rigging material and labor
Optional Built-in Secondary
Suspension Wire Rope
Mounts to hoist for maximum
security and durability
Allows use of secondary
suspension wire rope for
applications that require it
Eliminates possible loss/damage
because it is built-in
Adds versatility to hoist applications
Single Phase Three Phase
Working Load Limit (WLL) 1,000 lbs OR 1,500 lbs 1,500 lbs
Power Supply
208 VAC, 60 Hz (1,000 or 1,500 lbs)
OR
110 VAC, 60 Hz (1,000 lbs)
208 VAC, 60 Hz
Amperage at WLL
7.5 amps (208 V, 1,000 lbs)
OR
12 amps (208 V, 1,500 lbs)
OR
14 amps (110 V, 1,000 lbs)
7.5 amps
Wire Rope Diameter 5/16" (8 or 8.4 mm)
Right Regular Lay, IPS (Improved Plow Steel) or EIPS (Extra Improved Plow
User must verify that the wire rope meets or exceeds applicable codes for breaking
strength safety factor. US temporary applications require 6:1.
