Overspeed Reset Knob
UP Operation
Button
Emergency Stop
(Power Cut-off)
Power Indicator Light
Overspeed Brake
Test Button
DOWN Operation
Button
Remote Pendant Port
Carrying Handle
Power Supply Cable
Optional Top Limit Indicator
Primary Wire Rope
Insertion Point
Wire Rope Insertion Point for
Optional Secondary Wire Rope
Operator’s Manual
and Schematic
