81
SECTION F.3
PROBE AND SENSOR HOOKUP PROCDURE FOR
METER VERIFICATION TESTING ONLY
F.3.1 5000 MV Bird Dog Plus Probe Hookup Procedure for Single Phase MV
The following is a list of meter types that can be tested by testing both the meter and the meter
circuit at the same time. These are all CT rated meters:
Number of Steps
Required to Section Number Current
Verify Accuracy Location Connection
Form 3 1 F.3.1.1 Direct Connect or Clamp-on CT
Form 4 2 F.3.1.2 Direct Connect or Clamp-on CT
Form 5 2 F.3.1.3 Direct Connect or Clamp-on CT
Form 6 3 F.3.1.4 Direct Connect or Clamp on CT
Form 8 3 F.3.1.5 Direct Connect or Clamp-on CT
Form 9 3 F.3.1.6 Direct Connect or Clamp-on CT
The following is a list of meter types that can be tested by testing only the meter. These meters
have no CT’s associated with them:
Number of Tests
Required to Section Number Current
Verify Accuracy Location Connection
Form 1 1 F.3.1.7 Clamp-on CT
Form 2 1 F.3.1.8 Clamp-on CTs
Form 12 1 F.3.1.9 Clamp-on CTs
The direct connection referred to above is the duckbill cable as shown below.
