SPX 2045 User Manual

Introduction Waukesha Cherry-Burrell
Page 16 95-03009 10/2010
Dimensions
Figure 5 - Footprint Dimensions
B
F
G
D
X
Y
AA
AB
A
E
Z
CT100-046
CP
Sanitary Model Size (Inlet x Outlet)
Motor
Frame
2045
All
2065LV
All
2065
2-1/2x2
2065HV
3x2
2085LV
2x1-1/2
2075
2x1-1/2
2085
3x2-1/2
2085
4x2-1/2
2105
4x4
2105
6x4
Dim.
Callout
CP
inch
(mm)
CP
inch
(mm)
CP
inch
(mm)
CP
inch
(mm)
CP
inch
(mm)
CP
inch
(mm)
CP
inch
(mm)
CP
inch
(mm)
CP
inch
(mm)
CP
inch
(mm)
145JM
18.94
(481)
16.35
(415)
16.94
(430)
17.04
(433)
16.16
(410)
16.16
(410)
17.50
(445)
17.05
(433)
-- --
182JM
21.81
(554)
19.66
(500)
20.25
(514)
20.35
(517)
18.09
(459)
18.09
(459)
19.43
(494)
18.96
(482)
-- --
184JM --
19.66
(500)
20.25
(514)
20.35
(517)
18.09
(459)
18.09
(459)
19.43
(494)
18.96
(482)
25.13
(638)
25.16
(639)
213JM --
21.91
(557)
22.50
(572)
22.60
(574)
21.72
(552)
21.72
(552)
23.05
(585)
22.55
(573)
23.88
(607)
23.91
(607)
215JM --
21.91
(557)
22.50
(572)
22.60
(574)
21.72
(552)
21.72
(552)
23.05
(585)
22.55
(573)
26.56
(675)
26.59
(675)
254JM --
25.47
(647)
26.06
(662)
26.17
(665)
25.53
(648)
25.53
(648)
26.87
(682)
26.43
(671)
27.63
(702)
27.66
(703)
256JM -- --
27.81
(706)
27.92
(709)
25.53
(648)
25.53
(648)
26.87
(682)
26.43
(671)
29.38
(746)
29.41
(747)
284JM -- -- --
28.44
(722)
27.66
(703)
27.66
(703)
29.00
(737)
28.50
(724)
29.94
(760)
29.97
(761)
286JM -- -- --
29.94
(760)
29.16
(791)
29.16
(791)
30.50
(775)
30.00
(762)
31.44
(799)
31.47
(799)
324JM -- -- -- --
29.97
(761)
29.97
(761)
31.31
(795)
30.81
(782)
31.63
(803)
31.66
(804)
326JM -- -- -- --
31.47
(799)
31.47
(799)
32.81
(833)
32.31
(821)
32.87
(835)
32.91
(836)
