SPX 2045 User Manual

Waukesha Cherry-Burrell Parts Lists
10/2010 95-03009 Page 53
Type 1 Seal Components and Common Parts
1
Deflector 1 69-1
* Stationary Seal, Purebide
1 23-17
* Stationary Seal, Silicon Carbide
1 23-17A
* Stationary Seal, Tungsten Carbide
1 23-17F
3
Stationary Seal Retainer 1 23-78
4
1/4-20 x 1/2 Bolt 4 30-62
* Rotary Seal, Carbon
1 9-225A
* Rotary Seal, Purebide
1 9-225B
* Rotary Seal, Silicon Carbide
1 9-225C
* Rotary Seal, Tungsten Carbide
1 9-225F
6
1/4-20 x 3/8 Set Screw 2 30-178
7
Spring Retainer 1 23-77
* L-Gasket, FKM
19-37
* L-Gasket, EPDM
19-37E
* L-Gasket, Silicone
19-37R
* L-Gasket, FFKM
19-37K
* L-Gasket, substitute, Teflon
1 20-278 1
* Gasket Seal, Gore-Tex (used with 20-278)
1 T80041 1
* Seal O-Ring, FKM
1 V70224
* Seal O-Ring, EPDM
1 E70224
* Seal O-Ring, Silicone
1 S75224
* Seal O-Ring, FFKM
1 K75224
10
Washer, tabbed 1 43-87
11
Spring 3 24-65
18
Block, Water (For type 1 cascade) 1 134-2
19
8-32 x 1/4 Screw (For type 1 cascade) 1 30-176
20
1/4" Plastic Hose (For type 1 cascade) 1 74-1
21
1/4" Hose Fitting (For type 1 cascade) 1 78-18
Shim, 1" x .005" 143-215JM as req'd 35-1
Shim, 1" x .010" 143-215JM as req'd 35-2
Shim, 1" x .020" 143-215JM as req'd 35-3
Shim, 1-3/8" x .005" 254-326JM as req'd 35-4
Shim, 1-3/8" x .010" 254-326JM as req'd 35-5
Shim, 1-3/8" x .020" 254-326JM as req'd 35-6
PL5030-CH11
NOTES:
*
Recommended Spare Parts
1. T80041 must be used in conjunction with 20-278 if 20-278 is selected.
NOTES
ITEM
NO.
DESCRIPTION
QTY.
PER
PUMP
PART
NO.
22
2
5
8
9
