SPX 2045 User Manual

Waukesha Cherry-Burrell Parts Lists
10/2010 95-03009 Page 63
2085LV - 2085 Pump Parts
1
Casing (see 2085LV-2085 Casing Parts List) 1
2085LV Impeller, 8.7" Dia., 143-215JM, SM Bore 1 109723+ 1
2085LV Impeller, 8.7" Dia., 254-326JM, LG Bore 1 109741+ 1
2085 Impeller, 8.7" Dia., 143-215JM, SM Bore 1 109248+ 1
2085 Impeller, 8.7" Dia., 254-326JM, LG Bore 1 109249+ 1
Impeller Retainer, 143-215JM, SM, Bore 1 129-771X
Impeller Retainer, 254-326JM, LG, Bore 1 129-772X
* Impeller O-Ring, FKM
1 V70220
* Impeller O-Ring, EPDM
1 E70220
* Impeller O-Ring, Silicone
1 S75220
* Impeller O-Ring, FFKM
1 K75220
* Impeller O-Ring, PTFE ENCAPSULATED
1 T80220
Adapter, 143-184JM Frame, SS 1 122053+ 2
Adapter, 213-215JM Frame, SS 1 122055+ 2
Adapter, 254-256JM Frame, SS 1 122096+ 2
Adapter, 284-326JM Frame, SS 1 122057+ 2
3/8-16 x 1" Hex Screw, 143-184JM Frame 4 30-30
1/2-13 x 1-1/4" Hex Screw, 213-256JM Frame 4 30-36X
5/8-11 x 1-1/2" Hex Screw, 284-326JM Frame 4 30-105
3/8" Lockwasher 4 43-28
1/2" Lockwasher 4 43-16
5/8" Lockwasher 4 43-33
* Casing O-Ring, FKM
1 V70446
* Casing O-Ring, EPDM
1 E70446
* Casing O-Ring, Silicone
1 S75446
* Casing O-Ring, FFKM
1 K75446
* Casing O-Ring, PTFE ENCAPSULATED
1 T80446
10
Backplate 1 1-61X
11
Casing Clamp 1 119-69
Key-3/16", 143-215JM, SM Bore 1 65-3
Key-1/4", 254-326JM, LG Bore 1 65-4
PL5030-CH7
NOTES:
*
Recommended Spare Parts - available as kits for standard seals-see seal kit pages.
1.
2. Previously supplied as 2 pieces, an adapter and a seal guard; now a single piece.
PART
NO.
NOTES
2
ITEM
NO.
DESCRIPTION
QTY.
PER
PUMP
Trimmed impellers use the same part number and price; specify the diameter required in 1/8"
increments on order.
12
3
4
9
8
7
5
